STA Cheap Price High Super Molybdenum Disilicide Mosi2 Heating Elements
US$ 9.9 - 199
/ Piece
2 Pieces(Min. Order)
- Any China port
- T/T L/C D/P D/A Credit Card
You May Like
-
STA High Super Mosi2 Heating Elements1800C Grade With Factory Price
-
STA Hot Sale High Temperature Grade 1800 Molybdenum Disilicide Heater
-
Molybdenum Disilicide Heating Element / MoSi2 Rods With Clamps
-
STA Molybdenum Disilicide Ceramic U Type Mosi2 Heating Element
-
STA U Type MoSi2 Molybdenum Disilicide Heating Elements With High Quality
-
High Temperature Electric Furnace Molybdenum Disilicideheating Element/mosi2 Heating Element
Product Details
| Condition | New | Type | Duct Heater | |
| Power Source | Electric | Place of Origin | Henan, China | |
| Brand Name | STA | Model Number | STA 0017B | |
| Dimension(L*W*H) | Custom Size | Weight | Final Dimension | |
| Voltage | 220V | Power(W) | as requirement | |
| Certification | ISO9001 | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
U Type MoSi2 heater molybdenum disilicide heating elements with high quality
Molybdenum disilicide (MoSi2) heating element is a resistance generate-heating component made from MoSi2 or the basic material. It is used in high temperature under the oxidizing atmosphere, it looks like glass in its surface and form a light SiO2 glass film which can protect the element not to be oxidized. So this kind of element has unique effect for resisting oxidization in the high temperature. It is used to the highest temperature up to 1800C during oxidizing atmosphere. According to your request, our company can produce the products of Pole, "U", "W" and "U"-right angle shapes, etc.
MoSi2 heating element can usually make use of furnace temperature from 1300C to 1800C. It is extensively used in the industries of metallurgy, glass, ceramic refractory, crystal electronic device, industrial furnace manufacture, etc.. It is an essential ideal element when the products are sintering in the high temperature.
Order sample(U shape):
D1=6mm, D2=12mm, Le=200mm, Lu=180mm, A=30mm
Please specify as: dia6/12x200x180x30mm (dia D1/D2xLexLuxA mm)
D1 = the diameter of hot zone
D2 = the diameter of cold zone
Le = the length of hot zone
Lu = the length of cold zone
Physical Property:
| volume density | 5.5~5.6g/cm³ | bend strength | 5.5~25kg/cm² |
| vickers-hardness | (hv)570kg/mm² | porosity rate | 7.4% |
| water absortion | 1.2% | hot extensiblity | 4% |
Recommend surface load:
| Furnace Temp(°c) | 1400 | 1500 | 1600 | 1650 | 1700 |
| Surface looad of hot zone(W/cm²) | <18 | <15 | <12 | <10 | <8 |
Note: Shifting gear must be done quickly, otherwise high current surges may cause damage
