Home > Products > Furnace Parts > ceramic vacuum fiber insulated heater /panel
ceramic vacuum fiber insulated heater /panel
- QingDao port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
ceramic fiber insulated heater / heating module for klin
-
1200 degree ceramic fiber insulated heater/heating panel
-
STA Good Performance ceramic fiber insulated heater/heating panel
-
2015 hot sales ! STA new type fiber insulated heater/heating panel
-
STA ceramic fiber heater/heating panel for box furnace
-
ZhengZhou STA 1200C ceramic fiber heater/heating panel
Product Details
| Condition | New | Type | Duct Heater | |
| Power Source | Diesel | Place of Origin | Henan, China | |
| Brand Name | STA | Model Number | STA-MO72 | |
| Dimension(L*W*H) | as customized | Weight | as customized | |
| Voltage | 220v/380v | Power(W) | 6.8kw | |
| Certification | ISO CE | Warranty | 2 years | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
ceramic vacuum fiber insulated heater /panel
Ceramic fiber heaters offer some of the highest temperature heating element capabilities in the Watlow family of heaters. Heating units constructed of ceramic fiber insulation isolate the heating chamber from the outside. Ceramic fiber heaters are extremely low mass, high insulation value units with self-supported heating elements. Many applications can benefit from the convenience of the heating element and insulation combined into one package. It's lightweight, low-density properties make it ideally suited for high temperature applications requiring low thermal mass
Ceramic Fiber heaters
- Proprietary vacuum formed, ceramic fiber insulation
- Rated up to 1350° C
- Kanthal APM/A1 element wire
- Can be configured for line voltage operation, single or three phase
- Cylindrical, split tube, or rectangular configurations
- Alumina coating rated for 1800° C to prevent dust contamination
- Available with thermocouple holes
Ceramic Fiber Heater technical date
Thermal Response Power (watts) plus Hot & Cold Face Temperatures (°C) vs. Time for a test furnace composed of a custom cylindrical heater (6in. ID x 10in. OD x 6in. L, 1200W, 120V) with 2in. thick Alumina Silica Insulation Type AXL discs on each end. |
Electrical Change The electrical characteristics of these heaters change with temperature due to a shift in resistivity of the alloy used in the heating coil. At 1100°C there is a ~3.8% increase in resistance and decrease in current and power. |
Safe Operation Zone Fiber Insulated Heaters Type FIH are designed to operate at power densities up to 1500 watts/ft2 at 1100°C. They may, however operate at significantly higher power densities at lower temperatures and still provide long life. |
Fiber Insulated Heater Availability
ITEM | DESCRIPTION | SHIP WT. (lb.) |
CX15120A | C, 1in. x 3in. x 6in., 200w, 60V | 5 |
CX15180A | C, 3in. x 6in. x 12in., 1200w, 120V | 8 |
CX15270A | C, 8in. x 12in. x 12in., 3100w, 240V | 12 |
Ceramic fiber heater sizes:
Size D*W*H | Voltage / V | Power / W | Working temperature / °C | BD (kg/m3) |
200*120*80 | 220 | 1500 | 0~1200 | 280~330 |
190*200*130 | 220 | 3000 | 0~1200 | |
190*200*170 | 220 | 3000 | 0~1200 | |
300*200*120 | 220 | 3500 | 0~1200 | |
300*200*150 | 220 | 3000 | 0~1200 | |
300*200*200 | 220 | 4000 | 0~1200 | |
300*250*250 | 220 | 5000 | 0~1200 | |
350*250*160 | 220 | 4200 | 0~1200 | |
400*300*300 | 380 | 8000 | 0~1200 | |
510*300*200 | 220 | 8600 | 0~1200 | |
510*350*260 | 220 | 9900 | 0~1200 |
Applications:
Various electric heating furnaces
Smallest laboratory furnace, largest production furnace
Pipe heating
