Home > Products > Power Supply > Information Technical Equipment Power Supply 100W

Information Technical Equipment Power Supply 100W

FOB Price

Negotiable / Set

5000 Sets(Min. Order)

Port ShenZhen
Payment TermsT/T D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	Power-Tek, POWER-TEK
Model Number	SWPP-24004000-W	Output Type	Other, DC, Single
Connection	Desktop

Product Description

Specifications

power supply
1)output 24v 4a
2)CE,CCC,UL,UK,EK,SAA,PSE
3)OCP OVP SCP
4)2 years warranty

information technical equipment power supply 100W:

Input:100-240Vac 50-60HZ

Output Voltage 5-24V
Certificate GS UL UK PSE CCC KC SAA PSE

OCP/OVP/SCP

Precise design performance

Input Characteristics:

1:Input voltage

Rated Voltage AC 100-240V

2:Input Frequency

rated Frequency 50/60Hz

3 :Input Current

The maximum input current shall be less than 1.5A

4:Inrush Current

Peak inrush current shall be limited 45A within 10 ms at 230Vac( Cold Start).

5 :AC Leakage Current

The leakage current shall not exceed 0.25Aa

Output Charactristics:

1: I/P AC100-240V

2: O/P Frequency : 50-60Hz.

3: Voltage : DC 24V.

4: OP Rate: 5%.

5: Rated current OP: 4A

6: Ripple & Noise: 100mVp-p.

7: Efficiency: 73-95%.

8: Short circuit protection.

9: Overheating Protection.

10: Working temperature:0°C~+50°C.

11: Storage temperature: -20°C~+85°C.

12: Humidity: 10%-95%RH

Output :12V1.5A 24V1A12V2A 12V1.5A 15V1.5A 9V2A 5V2A

Quality certification CCC,UL,cUL,BS,GS,KC,PSE,SAA,CE etc.

Place of Origin : Guangdong, China (Mainland)

Port :FOBshenzhen

Packing: Poly Bag &Carton Box

1.Used quality safted components and purchased from famous supplier brand standard components, such as rectifier,MOSFET,capacitor,IC,transformer,inductance,fuse etc.

2.Meet EMC/EMI requirements.

3.Meet Rohs,SGS requirements.

4.Design laptop adapter electronics function and mechanism based on customer detail specification requirements.

5.Overall quality reliability test such as loading output,no-loading output,full load efficiency,noise data,short circuit protection,OCP,OVP,Hi-pot,Resistance,burning-in/aging,temperature shock,drop test,vibration test etc.

6.Load/no-load output tolerance:3%
