Docan Digital Flatbed Printer, Multifunctional Printer FRT3210 , Vinyl Printer

FOB Price

US$ 40,000 - 140,000 / Set

1 Set(Min. Order)

Port Shanghai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Plate Type	Flatbed Printer
Place of Origin	Shanghai, China	Brand Name	Docan
Model Number	FR3210	Usage	Other
Automatic Grade	Automatic	Voltage	220v
Gross Power	8kw	Dimensions(LWH)	5.51.61.3m
Weight	3125kg	Certification	CE,ISO
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Advantages of UV3210 Flatbed and Roll to roll Printer

Our UV roll to roll printer can detect thickness of media automatically and the printer head carriage can go up and down automatically.

It is equipped with automatic cleaning system and print head carriage anti-bumping device.

There are three kinds of printing speeds; draft mode; standard mode and high precision mode

Its tension system can be adjusted continuously.

White print head and innovative structural design.

Optimized ink-jet system and multi-domain vacuum printing platform,

Our UV roll to roll printer adopts Konica Minolta print head.

As a professional UV roll to roll printer manufacturer in China, we strive to provide various high-quality UV printers for our customers, In order to do this, we adopt the newest fiber data transmission mode, which can facilitate the transmission of data and enhance the anti-jamming capability. Furthermore, we develope a specialized control system for UV roll to roll printer on our own.

Technical Parameters of UV Flatbed and Roll to roll Printer UV3210

Model	DOCAN UV3210
Print head	KM-1024-14PL
Catagory	UV series
Print Technology	Drop-on-demand Piezo Electic
Nozzle Technology	Piezoelectric Inkjet
Print head controls	Print head temperature and voltage are software adjustable
Cloth feeding system	Automatic rotary motor can be driven to achieve optimal tension distributing
Cloth collecting system	Automatic motor rotatingφ 35cm
Material accepted	Roll to roll/ Sheet to sheet
Ink Characteristics	UV curing ink
Ink Reservoir	Refillable on the fly while printing/ 1000ml
Drying system	UV lamp
Rip software	Photoprint/ Onyx/ Caldrea
Color Management	Icc Based Color, Curves Adjustment, Density Adjustment
File Format	Tiff, Jpeg, Postscript 3, Eps and Pdf
Power supply	50/60hz 220v ( 10%) >30A
Operation Environment	Temperature 20℃ to 28℃ degrees
Humidity	40% to 70%
Product Model	Docan UV3210
Media width	3.3m
Printing size	3.2m
Media thickness	1-60mm
Nozzle Number	4/5/6/7/8/10/12/14/16pcs
Resolution	360dpi360dpi 360dpi720dpi
	720dpi360dpi 720dpi720dpi
	720dpi1440dpi 1440dpi1440dpi
Printing speed	In Draft mode up than 60 sq.m/h (8 heads)
	In Standard mode up than 38sq.m/h ( 8 heads)
	In High resolution mode up than 24sq.m/h (8 heads)
Colors	4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional
Outdoor life	2 years(use Docan ink)
Dimensions	5.51,61.3m
Weight	3125KG
