Digital UV Hybrid Printer

Specifications

Shanghai Docan Technologies Co., Ltd

Latest Product Catalog
UV2510
UV2030


UV2510 WITH 2.5m UV HYBRID PRINTER(ROLL2ROLL+FLATBED)

UV2510
UV HYBRID PRINTER
FEATURES:


Plate and sheet can be printed
Maximum material width 2.6 m
Maximum print width 2.5 m
Maximum print thickness 5cm
Automatic lift adjustment
Maximum 16heads 512 print system

8 heads color scheme

8  CMYK CMYK
8  CMYK LC LM+2W
8  CMYK LC LM W V
1.   Table size: 2 m X 3 m
2.   Material maximum thickness: 12 cm
3.   Nozzle technology: Konica512-14PL or 42PL, technology leading
4.   Servo System: Panasonic servo motor systems, stability is of overriding
5.   Negative pressure for the ink system: Japan SMC negative pressure ink supply system, White
6. Guide screw system: Taiwan HIWIN guide screw system (Mute)
7. Model with an optional 14PL/42PL nozzle, 4 heads, 6 heads, 8 nozzle configuration
8. Control System: DOCAN KUV control system, All Rights Reserved
9. RIP System: U. S. Photoprint 6.0
10. Transmission System: USB optical transmission, interference, to avoid printing garbage
11. Shutter system: Protection of printed material, will not zoom (paper, leather)
12. Nozzle automatic cleaning, regular cleaning without artificial
13. Vacuum adsorption system partition: Adsorption capacity, can partition adsorption, convenient operation
14. UV lamp system: Imported UK Primarc life of up to 800 hours or more
15. Aluminum Hard table: Table-free nail connections, beautiful wear
16. Used to print color separation system, without UV curing Road, smooth flat screen.
1.   Separations Staggered Technology

6 Nozzles   14 Nozzles with double white

8 Nozzles with double white
---------------------------------------------------------------------------------------------------------------------

2.  Table System
1.3X3cm suction hole
2.5mm aluminumadsorptiontable, no deformation

----------------------------------------------------------------------------------------------------------------------
3.  Vacuum System
1.  Japan SMC negative ink supply system
2.  USA imported ink filter, ink pump
----------------------------------------------------------------------------------------------------------------------
4.  Nozzle protection
1.  Nozzle bottom 3mm gaps, Effective protection sprinkler scratch
2.  Nozzle cavity protection, protection spray

----------------------------------------------------------------------------------------------------------------------
5.  Hardware system

1. Belt, belt from Italian imports increased accuracy and durability
2. Motor, 400W DC servo motor, built-in reducer, quiet movement
3. Drive, motor drive with DSP digital control.
4. Screw, guide rail import from Taiwan HIWIN
5. UV lamp, from British Primarc, trigger, transformers
6. All closed, raster to prevent the dust, raster can be more durable, print is not prone to defective products.

6. Machinery Manufacturing Process
1. Process Accuracy Control: Control of mechanical precision, mechanical precision control 6000mm ± 0.01mm
