Satellite TV Receiver 6*Tuner(DVB-S/S2/C/T/T2)+2*ASI input Multiplexer Scrambler

      Click  to Direct Online Chatting

 Outline

Shineco SNK6590 Tuner input ( ASI input) multiplexer scrambler is the latest multiplexing and scrambling device for digital TV broadcasting head-end system. The mux-scrambler 2 groups of ASI output and 2 corresponding IP output (share one gigabit DATA port, RJ45 interface). In conclusion, its high integration and cost effective design make this device widely used in the Next Generation of CATV Broadcasting system.

Features

• Fully comply with ISO13818 and EN300468 standard
• Integrated multiplexing and scrambling functions
• 6 tuner inputs ( tuner can be DVB-S/DVB-S2/DVB-C/ISDB-T)+2 ASI inputs or 8ASI input
• Support 2 channels TS re-multiplexing
• SPTS and MPTS code stream multiplexing
• Supports accurate PCR adjusting
• Support PID filtering, re-mapping
• Two groups( each group has 2 channels) separate TS output
• TS over UDP output as mirrors of ASI outputs(RJ45)
• Supports PSI/SI rebuilding, editing
• Supports DVB general scrambling system (ETR289), simulcrypt standards ETSI 101 197 and ETSI 103 197
• Support 4 different simulcrypt CAS
• Supports CAS remote connection scrambling
• Supports huge buffer memory and resists unexpected code stream
• Supports multiplexing the same program to all the output channels
• Alarming function
• Supports network remote upgrading
• LCD/keyboard and net management, support NMS/SNMP

Specifications

Shineco Company Brief Introduction and Advantage

Chengdu Shineco Technology Company is about 11 years experience in Digital TV headend DVB-C/T/T2/S2/IPTV and DSNG system.

we submitted to support our distributors and clients by means of successful experiences and perfect services. These added values make our products more worthy.

We work from 9:00 am to 24:00 pm to supply timelyservice for clients,if you choose us,we believe that we shall achieve a win-win situation in the future cooperation.  All our products enjoy 5 years warantty.  Welcome to contact us!

                  Go Here to Shineco Website Home Page for more Information

Encoder Series:

     MINI HDMI Encoder             MINI SDI Encoder                   HDMI+CVBS Encoder          8 in 1 HDMI Encoder

Encoder Modultor Series:

HDMI+CVBS to DVB-T         Encoder Modulator with Web  DVB-S2 Transmodulator    SD/HD Encoder Modulator

IPTV IRD, Gateway and Transcoder Series:

       4 in 1 IRD                            Tuner to SPTS IP Gateway        IPTV Transcoder                 Transcoder with CI Slot

FAQ

Q1:Do you support Sample order?

We accept MOQ 1 set, so we can accept Samples order before the real order per customers’ requirement,

sample are not free charge.

Sample delivery will take approximately 1-3 working days after  payment received,

bulk order lead time is about 5-15 days based on

your quantity.

Q2:What is your Payment Terms?

We can Support TT,Western Union,Paypal, you can also send money via direct online payment,meanwhile,

our company support Trade Assurance, which is 100% Production quality / on-time shippment / payment Protection.

Q3:Since there are so many company,how I can believe Shineco is the best factory we can cooperation?

1.First of all,our products and accessories have been inspected and tested by 3 times during every production process,

and all products will aging above 15 days before ship out,so excent quality is promised.

2.All products enjoy 5year warranty. If there is no man-made problem, we will replace or repair for your freely.

3. We own the best after sale service, if you face any problem,our team will response within 24 hours,and we can provide remote maintenance by teamviewer or telephone

Q4:Do you support OEM?

 Of course yes,OEM orders are warmly welcome,we can imprint your logo on products and let your logo shine anywhere.

Q5:How to place the order?

1.Directly place order from our alibaba website

2.Send your requirement to Tina email or add her skype: shineco.tina for details

Payment Terms:

1. Payment: T/T, Westerunion, Paypal or online pay

2.MOQ: 1 Set

3. Warranty: 5 Years
