Home > Products > Set top box > 2015 New Full HD 1080P Digital Terrestrial Receiver ISDB-T TV Box, ISDB-T Set Top Box for Brazil
2015 New Full HD 1080P Digital Terrestrial Receiver ISDB-T TV Box, ISDB-T Set Top Box for Brazil
- 100000 Set / Sets per Month
- china main port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Low Cost HD Digital ISDB-T Set Top Box Receiver For South America
-
Telecast ISDB-T SET TOP BOX, Receptor de TV Digital, full HD ISDB-T TV receiver with USB media player back. Quality Choice
-
HD Isdb-t hd set top box Mpeg4 .264 receiver ISDB-T Decoder/Conversor Digital/Receiver/STB for South America
-
ISDB-T Receiver, HD ISDB-T Set top box, ISDB-T Satellite Receiver
-
ISDB-T STB,ISDB-T Modulator,ISDB-T Equipment
-
ISDB-T Receiver MPEG4 H.264 ISDB-T STB for South America
Product Details
Place of Origin | Sichuan, China | Brand Name | Shineco | |
Model Number | M5 |
Product Description
2015 New Full HD 1080P Digital Terrestrial Receiver ISDB-T TV Box, ISDB-T Set Top Box for Brazil
Please add jacky skype to talk more details:Jacky.shineco
Hardware | ||||
CPU | v | |||
Memory | 32X16Mbit DDR2 Frequency1066 | |||
Flash | 32M bytes | |||
Demodulator Type | ISDB SOC Chip Set | |||
TUNER | Rafael R836 | |||
Front Panel | USB 2.0 Embedded One Host, | |||
4-digit LED display on front panel | ||||
red LED Standby,green LED Lock | ||||
Panel KEY, POWER, CH+ ,CH- | ||||
Rear Panel | Tuner RF input connector | EC-type IEC169-2 Female | ||
Tuner RF Loop through connector | IEC-type IEC169-24 Male | |||
HDMI V1.3/V1.4 | ||||
RCA CVBS AL AR Connector x1 | ||||
Ypbpr RCAx1 | ||||
Coaxial x1 | ||||
Power AC100~240V 50Hz/60Hz | ||||
Demodulation | ||||
Terrisal Receiver Standard | ISDB-T broadcast (1, 3, 13 segment) | |||
Input RF Frequency | VHF:177.143~213.143 MHz:UHF 473.143~803.143MHz. | |||
Bandwidth | 6MHz | |||
Demodulatio | QPSK / 16QAM / 64QAM/QPSK or DQPSK | |||
FEC | 1/ 2, 2/3, 3/4, 5/6, 7/8 Automatic | |||
Guard Interval | 1/4,1/8,1/16,1/32 | |||
FFT Mode | 2K/ 8K/32K | |||
Input level | -83 - -5dBm | |||
Sortware Features | ||||
•used for any ISDB-T countries like Brazil, Peru, Argentina,Chile,Venezuela,PhilippinesEcuador | ||||
•Supports all ISDB-T broadcast (1, 3, 13 segment), MPEG-2/MPEG-4 AVC/H.264 HD/SD Video , DiVX compliant | ||||
•Support 3D interface | ||||
•Support teletext/subtitle/muti-language | ||||
•Supported 7-Day EPG function, VBI Teletext | ||||
•AUTO, 16:9 Pillar Box, 16:9 Pan G Scan, 4:3 Letter Box, 4:3 Pan G Scan, 4:3 Full, 16:9 Wide Screen | ||||
•USB 2.0 for PVR,TIMESHIFT,software upgrade and media files playback | ||||
•Video output resolution: 480i/576i/480p/576p/720p/1080i/1080P | ||||
Decoder | ||||
Video Decoder | Compliant with: MPEG-4 part10/MPEG-2 ISO/IEC 13818 MPEG-4 Simple/Main/Advanced Profile@LEVEL3(10Mbps) MPEG-2 Main Profile# Main Level(15Mbps) H.264 MP#L3(10Mbps).H.264 HP L4.1(25Mbps) | |||
Audio Decoder | MPEG-1, MPEG-2 (Layer I/II), MP3, AC-3 (Dolby Digital), AAC-LC, WMA E-AC-3 (Dolby Digital Plus) decoding HE-AAC 5.1 multi-chhannel decoding | |||
Powerful Multimedia Features | ||||
MediaCodec | avi. mpg, .dat, .vob, .div, .mov, .mkv, .jpeg, .ts etc | |||
Audio Codec | WMA,MP3,AAC (.wma,.mp3,m4a) | |||
Photo Codec | JPEG, BMP, PNG | |||
License | ||||
Optional DTS, Dolby Digital, Dolby Digital Plus, RM/RMVB, Divx License. | ||||
Accessories | ||||
Accessories | gift box | |||
AV cable optional | ||||
HDMI cable optional | ||||
IR remote control | ||||
User Manual | ||||
Loading | ||||
Loading | machine size | 220*135*40mm | Packaged size | 52.5*45.5*25.5cm |
Pcs/Ctn | 20pcs | Carton weight | 16kgs | |
Loading for 40GP | 18360pcs | Loading for 20HQ | 9180pcs | |
Chengdu Shineco Technology Company is about 11 years experience in Digital TV headend
DVB-C/T/T2/S2/IPTV and DSNG system.
we submitted to support our distributors and clients by means of successful experiences and perfect services.
These added values make our products more worthy.
Shineco Team members are kind and warmly enough to help you find the best solution for your project and market,
we work from 9:00 am to 24:00 pm to supply in time service for clients,if you choose us,we believe that we shall achieve
a win-win situation in the future cooperation.
Q1:Do you support Sample order?
We accept MOQ 1 set, so we can accept Samples order before the real order per customers’ requirement,
sample are not free charge.
Sample delivery will take approximately 1-3 working days after payment received,
bulk order lead time is about 5-15 days based on
your quantity.
Q2:What is your Payment Terms?
We can Support TT,Western Union,Paypal, you can also send money via direct online payment,meanwhile,
our company support Trade Assurance, which is 100% Production quality / on-time shippment / payment Protection.
Q3:Since there are so many company,how I can believe Shineco is the best factory we can cooperation?
1.First of all,our products and accessories have been inspected and tested by 3 times during every production process,
and all products will aging above 15 days before ship out,so excent quality is promised.
2.All products enjoy 5year warranty. If there is no man-made problem, we will replace or repair for your freely.
3. We own the best after-sale service, if you face any problem,our team will response within 24 hours,and we can provide remote maintenance
by teamviewer or telephone
Q4:Do you support OEM?
Of course yes,OEM orders are warmly welcome,we can imprint your logo on products and let your logo shine anywhere.
Q5:How to place the order:
Send your requirement to Jacky email or add her skype: Jacky.shineco for details or invoice.
