Vickers Hardness Tester
- T/T Credit Card
You May Like
Product Description
Specifications
Vickers Hardness Tester HV-30Automatic loading and releasing mechanism
Adjustment of lighting source via hardware
Vickers Hardness Teste HV-30
Main Features
Automatic loading and releasing mechanism
Adjustment of lighting source via hardware
Adjustment of pressure holding time (0~30s)
Unique measurement conversion device and unique micro eyepiece one- time measurement readout device, ensuring easy use and high accuracy
The tester is specially designed for testing minute, thin samples or parts after surface coating or general mechanic cal part
Technical specifications
Test Load | 19.6N(2kgf),29.4N(5kgf),98.0N(10kgf),196N(20kgf),294N(30kgf),490N(50.0kgf) |
Hardness value symbol | HV2, HV3, HV5, HV10, HV20, HV30 |
Error range in display | ±3.0% |
Hardness value range in measure | 10HV2~2500HV30~2.0% |
Pressure loading & unloading method | Automatic |
Magnification of microscope | 100X |
Pressure holding time | 0~30s (5 second as input increment)µ m |
Minimum measurable unit | 1µm |
Maximum height of sample | 150mm |
Distance from indenter's center to outer wall | 130mm |
Main unit weight | Approx.38Kg |
Power source | AC220V/110V 50Hz/60Hz |
Machine size(L x W x H) | 452 x 200 x 620mm |
Standard delivery
Vickers indenter 1
Weight 3
Power cable 1
Lamp 2
Certificate 1
Manual 1
Test table (big, medium, small) 1each
Horizontal regulating screw 4
Vickers test block (high, medium) 1 each
Measuring microscope 1
Object lens 10X, 25X 1 each
Optional accessories
Forcipate test table
Cylindrical test table
X-Y plotter
Gradienter
Knoop indenter
Digital camera
Shutter line
Magazine
Special single page magazine
Photographic eye piece
Fine specimen measuring test table
Main body of photographic instrument linker
