Specifications

 LVTE Company other models of Ground source heat pump introduction:

Introduction:

1.LVTE company design, manufacture Scroll Geothermal Heat Pump, Screw Geothermal Heat Pump, Residential Geothermal Heat Pump and kinds of Ground Source Heat Pump.

2. These heat pump are all used for building heating and cooling to be as the central air conditioning system, It has high COP and saving energy, also can make hot water for daily life use.

3. Geothermal heat pumps form LVTE company have large cooling range from 1tons to 1500tons, and also large heating range.

4. LVTE company Geothermal Heat Pumps units has been gained many design patents in china.

5. Cooperate with world famous opponents like Copeland, Bitzer, Danfoss, Refcomp etc.

Features:

a. Heat and cool resource: From groundwater, surface water (rivers, lakes, sea) or soil;

b.Models:

LTWHM----Scroll Geothermal Heat Pumps (Cooling Range: 33-2340kw/Heating Range: 37-2632kw)

LTLHM---Screw Geothermal Heat Pumps (Cooling Range: 130-2340kw/Heating Range: 142-2632kw)

LTMLH---Screw Flooded Geothermal Heat Pump (Cooling Range: 247-3600kw/Heating Range: 260-3850kw)

LTWH---Residential Geothermal Heat Pump (Cooling Range: 7.2-37kw/Heating Range: 8.6-41kw)

c.Compressor: world famous brand semi-closed screw-type or fully closed scroll-type compressors;

d.Running advantage: Low energy consumption, stable operation, little vibration, low noise.

e.Components: Using high quality imported components, system with optimal design, stable operation of unit;

f.Refrigerants: Environment Protection refrigerants like R134a, R407C, R410A and other as request; No combustion, no smoke, no boiler or cooling tower makes the environment more beautiful.

g.Low running charge: The running charge only 1/3 to 1/2 of the traditional air conditioner;

h.Application: hotels, restaurants, hospitals, office buildings, theaters, stadiums, residential quarters, textile, food, medicine, metallurgy, chemicals and boiler works etc.

Certificate of Products
