Air Cooled Water Chiller and Heat Pump
US$ 500 - 20,000
/ Set
1 Set(Min. Order)
- Qingdao
- T/T
You May Like
-
Modular Design High Quality Screw Compressor Air Cooled Chiller
-
Quality Modular Type LTWF Air Cooled Scroll Compressor Water Chiller
-
LTLF Series Air Cooled Scew Compressor Water Chiller 80-1000KW
-
LTWF Series Box Type Scroll Air Cooled Water Chiller
-
LTWF Series Box Type Scroll Air Cooled Water Chiller
-
LTLF Series Air Cooled Screw Compressor Water Chiller and Heat Pump
Product Details
| Place of Origin | Shandong, China | Brand Name | LYTTE or OEM | |
| Model Number | LTWF(R) | Type | HVAC Systems |
Product Description
Specifications
Air Cooled Water Chiller and Heat Pump-Low noise water pump
-Energy saving fan
-CE certificate
-Strict test before delivery
Quality Modular Type LTWF Air Cooled Scroll Compressor Water Chiller and Heat Pump
| Type LTWF(R)— | 10 | 12 | 15 | 17 | 20 | 25 | 30 | 35 | 40 | 50 | 60 | 70 | 95 | 120 | 140 | |
| Cooling capacity kW | 9.8 | 12.2 | 14.8 | 17.5 | 20.1 | 24.5 | 29.6 | 34.5 | 41.5 | 50.2 | 60.2 | 68 | 94.5 | 118 | 138 | |
| Refrigeration input power kW | 3 | 3.8 | 4.6 | 5.4 | 6.2 | 7.6 | 9.2 | 10.7 | 12.9 | 15.6 | 18.8 | 21.2 | 29.5 | 36.8 | 43.1 | |
| Heating capacity | 11.2 | 13.1 | 16.3 | 18.8 | 22.1 | 26.9 | 32.6 | 37.9 | 45 | 55.2 | 66.2 | 76 | 104 | 129.8 | 151.8 | |
| Heating input power kW | 3.2 | 3.6 | 4.5 | 5.2 | 5.8 | 7.4 | 9 | 10.5 | 12.5 | 15.3 | 18.3 | 21 | 28 | 35 | 41 | |
| Amount of heat recovery kW | 3.7 | 4.3 | 5.3 | 6.2 | 7.3 | 8.7 | 10.6 | 12.5 | 14.8 | 18.2 | 21.8 | 25.1 | 34.3 | 42.8 | 50.1 | |
| Refrigerant | Species | R22(R134a/R407C) | ||||||||||||||
| Charge kg | 2.6 | 3.3 | 4 | 4.7 | 5.5 | 6.7 | 8 | 9 | 10.6 | 12 | 13.5 | 18 | 21 | 27 | 34 | |
| Power | 380(220)V/50Hz/3Φ | |||||||||||||||
| Compressor type | Imported hermetic scroll type | |||||||||||||||
| Compressor Q'TY | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 3 | 2 | |
| Number of refrigerant circuits | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 3 | 2 | |
| Air-side heat exchanger fan | Low noise axial flow | |||||||||||||||
| Fan number | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 3 | 4 | |
| Air-side heat exchanger | Inner grooved copper tube fin series | |||||||||||||||
| Evaporator | Type | Circulation-type tube/plate heat exchanger | ||||||||||||||
| water pressure | 22.3 | 23.2 | 25 | 26.1 | 27.5 | 30.1 | 32.3 | 34.7 | 31.5 | 32.9 | 35.6 | 38.3 | 41. 2 | 42.5 | 45.5 | |
| water flow | 1.7 | 2.1 | 2.5 | 3 | 3.5 | 4.2 | 5.1 | 6 | 7.1 | 8.6 | 10.3 | 12 | 14.6 | 17.2 | 24 | |
| Interface(mm) | DN20 | DN20 | DN20 | DN32 | DN32 | DN32 | DN50 | DN50 | DN50 | DN50 | DN50 | DN65 | DN80 | DN80 | DN100 | |
| Heat recovery | Type | Circulation-type tube/plate | ||||||||||||||
| water pressure | 21.4 | 22.3 | 23.1 | 24.5 | 25.6 | 27.2 | 29.7 | 31.2 | 29.2 | 30.1 | 32.1 | 34.5 | 37.3 | 38.3 | 40.9 | |
| hot water output m3/h | 0.6 | 0.74 | 0.9 | 1.1 | 1.3 | 1.5 | 1.8 | 2.1 | 2.5 | 3.1 | 3.6 | 4.2 | 5.7 | 7.1 | 8.3 | |
| Interface (mm) | DN15 | DN15 | DN15 | DN15 | DN20 | DN20 | DN25 | DN25 | DN32 | DN32 | DN32 | DN40 | DN40 | DN50 | DN50 | |
air cooled water chiller and heat pump unit is a new generation of modular unit. This unit is energy saving and convenient in use,
which has the function of reverse cycle automatic defrosting, double steps automatic anti-freezing, built-in self-diagnosable system, and is controlled by microcomputer. Applicable to hotels, villas, hospitals, cinemas, stadiums, recreations,
office blocks, factories and so on. It can also provide chilled water or moderate hot water for industria purpose.
The unit is suitable for installing in outspace such as roof, floor and porch, left off the boiler room and the special room, decreased the
investment of building project. And no need of cooling tower and cooling water pump, this unit saves water greatly. And the unit is easy to
install, manage and maintain
