1000ft 0.57mm 23AWG 4 Pairs FTP Cat6 Lan Cable
- 20000 Carton / Cartons per Month
- Shanghai/Ningbo
- T/T D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Dong Sheng | |
| Model Number | 1000ft 0.57mm 23AWG 4 Pairs FTP Cat6 Lan Cable | Type | Cat 6 | |
| Number of Conductors | 8 |
Product Description
1000ft 0.57mm 23AWG 4 Pairs FTP Cat6 Lan Cable
FTP Cat6 Network Cable
We can ensure the cable pass FLUKE TEST 100% for CU conductor, with a high
performance in your Cabling solution, or projec.
UTP Cat6 Network Cable,Lan Cable Cat6 UTP
1. Certification: CE. RoHS,REACH,ISO Listed
2. Compliance: ETL verified ANSI TIA/EIA568-2, ISO/IEC 11801. RoHS Compliant.
3.Application: 100Base-TX, 100VG-AnyLan, 1000Base-T, ATM, Noisy Environment
4. Remark: 250HMZ 550MHz ATM 155MBPS, 100mbps TPDDI, Fast Ethernet etc
Specifications:
UTP Cat6 Network Cable,UTP Cat6 Communication Cables,Lan Cable Construction:
UTP Cat6 Network Cable Technical Performance(100m)
Frequency MHz | Impedance ohm | RL ≥dB | Attenuation ≤dB/100m
| NEXT ≥ dB/100m | ELFEXT ≥ dB/100m | PS NEXT ≥ dB/100m | PS ELFEXT ≥ dB/100m | NVP
|
1 | 100±15 | 20.0 | 2.0 | 65.3 | 63.8 | 62.3 | 60.8 | 68% |
4 | 23.0 | 4.1 | 51.7 | 51.7 | 53.3 | 48.7 | ||
10 | 25.0 | 6.5 | 43.8 | 43.8 | 47.3 | 40.8 | ||
16 | 25.0 | 8.2 | 39.7 | 39.7 | 44.2 | 36.7 | ||
20 | 25.0 | 9.3 | 37.8 | 37.8 | 42.8 | 34.7 | ||
31.25 | 23.6 | 11.6 | 33.9 | 33.9 | 39.9 | 30.9 | ||
62.5 | 21.5 | 17.0 | 27.8 | 27.8 | 35.4 | 24.8 | ||
100 | 20.1 | 22.0 | 23.8 | 23.8 | 32.3 | 20.8 | ||
*155 | 100±18 | 18.8 | 28.1 | 20.0 | 20 | 29.4 | 17.0 | |
*200 | 18.0 | 32.4 | 18 | 18.0 | 27.8 | 15.0 | ||
*310 | 100±22 | 16.7 | 41.8 | 14 | 14.0 | 24.9 | 11.0 | |
*350 | 16.3 | 44.9 | 13 | 13.0 | 24.1 | 10.0 |
UTP Cat6 Network Cable Applications: Cat6 Communication Cables
1.Computer Network Cabling Project.
2.Broadband Network Communication.
3.Digital ISDN Network and ATM 155Mbps Network
4.Ethernet Network
5.Audio and Data Transmission
UTP Cat6 Network Cable,Lan Cable,Network Cable Package
Factory Show
Products Certifications
Exhibition Trade Show
We attend to 3-5 Fairs in Beijing CCBN,Hongkong, Guangzhou, and aboard, to meet with the old customer, also show our company to the future new customers
SUPPLY KINDS OF CABLES:
1) Lan Cable / Network Cable UTP/ FTP /SFTP Cable Cat5e Cat6 Cat3
2) 75 ohm Coaxial Cable RG6 RG59 RG7 RG11
3) Telephone Cable,Telephone Drop Cable, PTT298 Cable , PTT299 Cable
4) Security Alarm Cable / Fire Alarm Cable
5) Optical Fiber Cable
6) Speaker Cable / Power Cable / Electrical Cable / Multi-Core Cable
7) Siamese CCTV Cable RG59+2C , KX6+2C , RG6+2C
8) Trunk Cable QR750 QR540 QR500 QR412
9) KoaxialKable CT100,CT165, KX6, KX8,17VATC,19VATC,SAT703,SAT602
10) 50 ohm Coaxial Cable RG174 RG58 RG8 RG213 RG214 RG223
11) 50ohm Cable LMR195 LMR200 LMR240 LMR300 LMR400 LMR500 LMR600
12) 75 ohm Coaxial Cable 3C-2V, 5C-2V, 4C-FB, 5C-FB
13) 50 ohm Coax Cable 3D-FB,4D-FB,5D-FB,7D-FB,8D-FB,10D-FB,Feeder Cable 1/2, 3/8,5/87/8
14) Mini Coax Cable: RG591885A,8218 Cable,1.37mm,0.81mm ect
15) Cabo Coaxial RG6 RG59 RG11 QR500 RF4mm
16) Telecom Cable BT3002, PCM Cable, Multi-Core Coax Cable
17) Coaxial Cable Connector(BNC,RCA,Female, Male)
18) Indoor TV Antenna, Outdoor TV Antenna,Satellite Antenna
19) CATV Transimitter, CATV Amplifier,CATV Receiver
20) Optical Fiber Cable (GYXTY, GYXTW, ADSS, FTTH ,GYXTC8S,GYXTC8Y etc.)
