Corning Quality FTTH Fiber Optica Cable

FOB Price

USD $0.001 - $100 / Kilometer

10 Kilometers(Min.Order)

Supply Ability 10000 Kilometer / Kilometers per Month
Port Shanghai/Ningbo
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	Dong Sheng
Model Number	Corning Quality FTTH Fiber Optica Cable		Type	Coaxial

Product Description

Corning Quality FTTH Fiber Optica Cable

FTTH Fiber Optica Cable

Fiber Optic Cable-FTTH indoor outdoor G657a LSZH jacket Cable

1. Optical Fiber Cable Recommended Laying Methods:

Used as access building cable

Used in indoor cabling, especially used for FTTH.

2. Fiber Cables Structure Characters:

Good mechanical and environmental characteristics.

Flame retardant characteristics meet the requirements of relevant standard.

The mechanical characteristics meet the requirements of relevant standard.

Soft, flexible, easy to lay and splice, and with big capacity data transmission.

Meet various requirements of market and clients.

3. optical cable Technical Data:

		G.652D	G.657A	50/125μm	62.5/125μm
Attenuation (+20°C)	@850nm			≤3.0 dB/km	≤3.5 dB/km
	@1300nm			≤1.0dB/km	≤1.0dB/km
	@1310nm	≤ 0.45 dB/km	≤ 0.40 dB/km
	@1550nm	≤ 0.30 dB/km	≤0.30dB/km
Bandwidth (Class A)	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth (Class A)	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength λcc		≤1260nm	≤1480nm

Fiber Count	Cable Diameter mm	Cable Weight kg/km	Tensile Strength Long/Short Term N	Crush Resistance Long/Short Term N/100mm	Bending Radius Static/Dynamic mm
1	(2.0±0.2)×(3.0±0.2)	10.5	30/60	300/1000	15/30
2	(2.0±0.2)×(3.0±0.2)	10.5	30/60	300/1000	15/30
4	(2.0±0.2)×(3.5±0.2)	11	30/60	300/1000	15/30
6	(2.0±0.2)×(4.0±0.2)	12	30/60	300/1000	15/30

4. Package

1. 2km/box , 2 boxes /carton , 500 cartons /20ft container . as customer need, OEM WELCOME

2. Wooden drum can be supplied

5. Products Photos:

Product Certificate:

Factory and Production line

Exhibition Trade Show

Other Cables:

1) Lan Cable / Network Cable UTP/ FTP /SFTP Cable Cat5e Cat6 Cat3

2) Telephone Cable,Telephone Drop Cable, PTT298 Cable , PTT299 Cable

3) Security Alarm Cable / Fire Alarm Cable

4) Optical Fiber Cable

5) Speaker Cable / Power Cable / Electrical Cable / Multi-Core Cable

6) Siamese CCTV Cable RG59+2C , KX6+2C , RG6+2C

7) Trunk Cable QR750 QR540 QR500 QR412

8) KoaxialKable CT100,CT165, KX6, KX8,17VATC,19VATC,SAT703,SAT602

9) 75 ohm Coaxial Cable RG6 RG59 RG7 RG11

10) 50 ohm Coaxial Cable RG174 RG58 RG8 RG213 RG214 RG223

11) 50ohm Cable LMR195 LMR200 LMR240 LMR300 LMR400 LMR500 LMR600

12) 75 ohm Coaxial Cable 3C-2V, 5C-2V, 4C-FB, 5C-FB

13) 50 ohm Coax Cable 3D-FB,4D-FB,5D-FB,7D-FB,8D-FB,10D-FB

14) Mini Coax Cable: RG591885A,8218 Cable,1.37mm,0.81mm ect

15) Cabo Coaxial RG6 RG59 RG11 QR500 RF4mm

16) Telecom Cable BT3002, PCM Cable, Multi-Core Coax Cable

17) Coaxial Cable Connector(BNC,RCA,Female, Male)

18) Indoor TV Antenna, Outdoor TV Antenna,Satellite Antenna

19) CATV Transimitter, CATV Amplifier,CATV Receiver
