high-tech low noise wood chips dryer with CE approved

Structure of wood chips dryer:

1,hopper; 2.dosing machine; 3.incoming material feeder; 4.heating resources; 5.drying roller; 6.discharge feeder; 7.cyclone; 8.draft fan; 9.belt conveyor; 10.variable motor; uction gear.

Description of wood chips dryer:

·On the basis of taking and absorbing the APV ANHYDRO A/S technology and soul of the same kind domestic drier, our factory and APV have developed this machine.

·This is a new kind of drying equipment used for drying the materials, such as paste state, filter cake state, thermal sensitive powder and particles.

·Our factory is equipped with the test sample machine, which can be used for carrying out the drying tests of various feeds for our users and for supplying the data and for helping the type selection.

The inner part of the sawdust rotary dryer

Performance and features of wood chips dryer

1. Our dryer is designed with anti-sticky drum-wall and assembled material-lifting board.

2. This drying equipment is divided into secondary-granulating section, balling section, polishing section and drying section, etc. What worth mentioning is that our dryer features convenient installation and transportation as a result of its flange connection?


3. This large sized drying equipment is primarily composed of vibrating feeder, heating furnace, drying device, and air intake and air outlet device, and more.

4.The vibrating feeder enables materials to spread uniformly on the mesh belt.

5. An air-intake fan with large air flow blows away water content of materials, and then the water content will be discharged from the air-outlet.

6. Our dryer has the features of low noise, little pollution and good drying effect.

 The pedestal of the rotary dryer                                        the cyclone of the rotary dryer

the draft fan of the rotary dryer                                          the motor of the rotary dryer

Working Principles of wood chips dryer:

1.Wet materials were sent to the hopper by belt conveyor or bucket elevator and through hopper feeding pipe are sent to the inside.

2.Adjust to the feeding pipe slope so that the wet materials can flow smoothly down the cylinder dryer, dryer cylinder is located in a slope.

3.The materials are sent here from higher end and the heat is sent here from the lower end, thus the materials and the heat will fully contact because of the gravity force.

4.During the materials moving forward in the cylinder, are directly and indirectly dried by the heater and are sent to the discharge feeder by with the rotation of the cylinder, the materials flow down the lower the belt conveyor or spiral conveyor.

Applications of wood chips dryer:

·A wood chips dryer is a kind of mechanical equipment which uses heat energy to reduce the water content of materials.

·Our wood chips dryer is mainly used in building materials manufacturing, metallurgy and chemical industry, sand and cement production industry, etc. To dry mineral slag, limestone, coal powder and clay, etc.
·If it is used in combination with our coal gasified, our wood chips dryer can also be used for fine chemical drying.
·Our wood chips dryers are also regularly used in drying wood chips, coal slime, and compound fertilizer production lines etc.
