Product Details

Place of Origin	Hebei, China		Brand Name	TUOFANG
Model Number	TF-OL-077		Material	Steel

Product Description

TOP quality G455/30/50 Welded Steel Plate

G455/30/50 Welded Steel Plate

Surface treament	galvanized	Color	Black,white,grey,blue,green,,yellow,red
Material	carbon steel,aluminum,stainless steel	Size	bearing bars pitch can be set to 12.5,15,20 or n30mm(n=1~5),cross bars pitch can be set to 50 or n100mm,(n=1~5),we also can manufacture special pitch according to clients
Feature	Save 28%-30% raw materials High dimensional accuracy Attractive appearance Have strong load ability
Advantage	Capable design can make grating customized according to site requirement Material Stainless Steel Reasonable price

Detailed images

Specification:

Series	Pitch of Bearing bar	Cross-bar Pitch	Specification of bearing bar load(width×thickness)
Series	Pitch of Bearing bar	Cross-bar Pitch	20×3	25×3	32×3	40×3	20×5	25×5
1	30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
1	30	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
2	40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
2	40	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
3	60	50		G253/60/50	G253/60/50	G403/60/50	G205/60/50	G255/60/50
Series	Pitch of Bearing bar	Cross-bar Pitch	Specification of bearing bar load(width×thickness)
Series	Pitch of Bearing bar	Cross-bar Pitch	32×5	40×5	45×5	50×5	55×5	60×5
1	30	100	G325/30/100	G405/30/100	G455/30/100	G505/30/100	G555/30/100	G605/30/100
1	30	50	G325/30/50	G405/30/50	G455/30/50	G505/30/50	G555/30/50	G605/30/50
2	40	100	G325/40/100	G405/40/100	G455/40/100	G505/40/100	G555/40/100	G605/40/100
2	40	50	G325/40/50	G405/40/50	G455/40/50	G505/40/50	G555/40/50	G605/40/50
3	60	50	G325/60/50	G405/60/50	G455/60/50	G505/60/50	G555/60/50	G605/60/50

Packaging & Shipping

packed In bundle with 6 circles of steel stripe, each bundle about 2mt
