Home > Products > Blow Molding Machine > extrusion blow molding machine blow molded tool case
extrusion blow molding machine blow molded tool case
- 0 per Month
- ningbo shanghai
- T/T
You May Like
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PP | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Zhejiang, China | |
| Brand Name | SHENGDA | Model Number | zk-110B |
Product Description
Specifications
extrusion plastic blow molding machine machinerysuit for PE,PP,PS PA,HDPEetc
plastic drum,water container,toolboxes,chairs.
ZK-110B automatic extrusion plastic blow molding machine machinery
plastic drum,water container,toolboxes,chairs.chemical drum, gasoline tank,bus seat, desk board etc hollow plastic products.
PLC & touch screen, bilingual
Energy saving 40-50%, accumulator.
3 tie bar & 2 cylinder & liner guide.
specification | unit | zk-110B |
max container capacity | L | 160 |
machine dimension(L*W*H) | M | 7.5*3.3*4.5 |
total weight | ton | 18 |
clamping unit |
|
|
clamping force | KN | 700 |
platen opening stroke | mm | 600-1600 |
max mould size(W*H) | mm | 1000*1200 |
mould thickness | mm | 610-800 |
power |
|
|
max drive | KW | 22 |
total power | KW | 125 |
fan power for screw | KW | 0.72 |
air pressure | Mpa | 0.7 |
air consumption | m3/min | 0.9 |
average energy consumption | KW | 45 |
extruder unit |
|
|
screw diameter | mm | 110 |
screw L/D ratio | L/D | 28:1 |
plasticizing capacity | kg/hr | 180 |
number of heating zone | zone | 6 |
extruder heating power | KW | 36 |
extruder driving power | KW | 45 |
accumulator head |
|
|
number of heating zone | zone | 6 |
power of die heating | KW | 36 |
max die-pin diameter | mm | 550 |
accumulator volume | L | 20 |
