Home > Products > F,K,S,R Series Gear Units > K167 KAF167 Ratio of 17.28~ 163.91gear Box Motor Helical Gears Hardened Tooth Surface Modular One-piece Gear Speed Reducer
K167 KAF167 Ratio of 17.28~ 163.91gear Box Motor Helical Gears Hardened Tooth Surface Modular One-piece Gear Speed Reducer
You May Like
-
K77 KAF77 Ratio of 7.24 ~ 192.18 Gear Box Motor Helical Gears Hardened Tooth Surface Modular One-piece Gear Speed Reducer
-
K87 KAF87 Ratio of 7.19 ~ 197.37 Gear Box Motor Helical Gears Hardened Tooth Surface Modular One-piece Gear Speed Reducer
-
K107 KAF107 Ratio of 8.74 ~ 141.46gear Box Motor Helical Gears Hardened Tooth Surface Modular One-piece Gear Speed Reducer
-
K97 KAF97 Ratio of 7.19 ~ 197.37 Gear Box Motor Helical Gears Hardened Tooth Surface Modular One-piece Gear Speed Reducer
-
K47 KAF47 Ratio of 5.81 ~ 131.87 Gear Box Motor Helical Gears Hardened Tooth Surface Modular One-piece Gear Speed Reducer
-
K127 KAF127 Ratio of 8.68 ~ 146.07gear Box Motor Helical Gears Hardened Tooth Surface Modular One-piece Gear Speed Reducer
Product Details
| Place of Origin | Hebei, China | Brand Name | WOSEN | |
| Model Number | K167/KA167/KAF167 | Gearing Arrangement | Bevel / Miter | |
| Output Torque | 32000N.m | Rated Power | 11~200KW | |
| Input Speed | 1450r/min | Output Speed | 0.1r/min-1450r/min |
Product Description
Specifications
K167 Helical bevel gear reducer/gear box/gearbox
1.with warranty
2.as design
3.IS9001
4. warranty
K167 Helical bevel gear reducer/gear box/gearbox
Specifications
1:Helical-bevel gear two-stage reducer
2:Compact structure, high efficiency
3:Quenched 20CrMnTi for gears
Technical data:
1,output torque:200-50000(N.m)
2,rated power:0.18-200(kw)
3,input speed:≤1500 (rpm)
4,output speed:≤280(rpm)
5,transmission ratio:≥5.36
6,series:3
7,install form:M1-M6
8,Model no. :K/KA/KF/KAF/KH/KHF(37/47/57/67/77/87/97/107/127/157/167/187)
Specifications
This gear speed reducer is a new transmission machine designed & manufactured by helical-bevel gear transmission principle.
1. High mechanical efficiency: 94%-98% (depends on the transmission steps);
2. Input form: flange input, direct motor input, shaft input;
3. Materials of gear speed reducer body: HT250 high-strength cast iron;
4. Materials of shafts:42CrMo alloy steel;
5. Materials of gears : 20CrMnTi alloy steel;
6. Heat treatment: tempering, cementiting, quenching;
7. Surface hardness of gears: HRC58°-62 °;
8. Maching precision of gears: 6-5GRADE;
9. Brand of bearings: HRB, LYC,ZWZ,NSK;
10. Noise of gear speed reducer : 60-68dB.
