Home > Products > Special Vihicles > HBT80.14.161RSD Trailer Concrete Pump
HBT80.14.161RSD Trailer Concrete Pump
- 30 Set / Sets per Month
- SHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Hunan, China | |
| Brand Name | ZOOMLION | Model Number | HBT80.14.161RSD |
Product Description
Specifications
We seeking the best for your around the world. Our persistence pursuit is provide the most suitable concrete pump for you.
A,Strong power serve for you
We seeking the best for your around the world. Our persistence pursuit is provide the most suitable concrete pump for you.
1.Engine
The engines equipped are from world famous brands such as VOLVO, DEUTZ and so on. They are powerful, environmental protection and energy-saving. The motors equipped are from domestic famous brands, they are steady and reliable.
2.Throttle double insurance
The perfect combination of manual and auto throttle provides you convenience.
3.Top brand main pump
Main pumps are original imported from Germany Rexroth and Hawe, they feature first-class quality and reliable.
1.Double-pump and double-circuit hydraulic system
The pumping loop single provides oil, thus the energy can be fully used and it can realize long-distance and large opening high pressure pumping. Control loop single provides oil, thus realize powerful swinging. The pumping loop and control loop are entirely separated, thus it is easy to check and find fault, and is also easy to maintain and overhaul.
2.Concrete pistons auto-retract technique
The time of replacing a piston was shortened from 2 hours to 15 minutes, it asks for less labor and time. Mechanical and hydraulic double limitations provide safety and reliability.
3.High-low pressure auto-switch
Technical Data
Items | Units | HBT80.14.161RSD | |
Whole performance of machine | Max. theo. concrete output | M3/h | 82/52 |
Concrete pumping pressure | Mpa | 14/8 | |
Distribution valve style |
| S pipe valve | |
Concrete cylinder specification×stroke | mm | Φ200×1800 | |
Hopper capacity ×feeding height | L×mm | 600×1400 | |
Outlet diameter | mm | Φ180 | |
Power system | Rated power | kW | 161 |
Configuration | Circuit type |
| Open circuit |
High-low pressure shifting |
| Block revolving type | |
Fast-replace concrete piston |
|
| |
Electric display |
|
| |
Water cooling |
|
| |
Cleaning machine |
|
| |
Wireless remoter |
|
| |
Other parameters | Max. Grain diameter | mm | Slick scree: 50 Scree:40 |
Inside diameter of delivering pipe | mm | φ125/φ150 | |
Dimensions:length×width×height | mm | 6800×2200×2700 | |
Total weight | kg | 7300 | |
