GSD-I Tractor Type Water Well Drilling Rig

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drilling Rig
Place of Origin	Shandong, China	Brand Name	BZ
Model Number	GSD-I Tractor Type Water Well Drilling Rig	Usage	Water Well

the engineering and water-well drilling rig adopts large gantry frame whose up and down is controlled by mechanical system,

SPECIFICATIN:-

Model	GSD-I
Drilling diameter	90-600 (mm)
Drilling depth	120(m)
Length of Drill pipe	3(m)
Diameter of Drill pipe	φ60 φ73 φ89 φ95(mm)
Dimension	Working conditions:4785×2020×5650
Dimension	Transport conditions::6000×2020×2880
Chassis support Form	mechanical screw
Rise and fall of the tower type	armstrong's patent
The weight of whole machine	2500 (kg)
Chassis	Two wheel tractor chassis
Power head diameter	φ35,φ60,φ81,
Pressure capacity	0-15 (kN)
Enhance the speed of power head	0.25 0.15 (m/s)
Power head speed	A( forward: 17,30,66)(reversal:13,23,50)(r/min)
Power head speed	B(forward:47,81,178)(reversal:36,62,137)(r/min)
Power head lift:	94.55 (kN)
Main hoist lifting force	18.54 (kN)
Power	Diesel Engine
Rated Power	22(kW)
Equipped pumps	FSB-50 Composite two-stage pump
Pump flow:	50 (m3/h)
