DAKE disposable plastic thermoforming machine
- 15 Set / Sets per Month
- shanghai
- T/T
You May Like
-
DAKE disposable plastic thermoforming machine
-
DAKE disposable plastic cup thermoforming machine
-
DAKE disposable fast food box plastic thermoforming machine
-
plastic tray, cup making machine
-
DAKE automatic plastic PP/PS/PE/ABS/ thermoforming machine price
-
automatic thermororming machine for disposable container
Product Details
| Condition | New | Product Type | Plastic Cup | |
| Place of Origin | Shanghai, China | Brand Name | DAKE | |
| Model Number | DT66A | Voltage | 3-N AC380V±15V ,50Hz | |
| Power(W) | 83KW | Dimension(L*W*H) | 9.5m*1.5m*2.7m | |
| Weight | 5000kg | Certification | Other, ISO9001 | |
| Warranty | 1 YEAR | After-sales Service Provided | Overseas service center available |
Product Description
Specifications
disposable plastic thermoforming machine plastic cup, lid, bowl making machine, PP, PE, PET, HIPS, PVC, biodegradable materialplastic thermoforming machine
Plastic cup, box, other containers making machine.With high speed and best quanlity.
Technical Parameter
Forming Area | 510mm *570mm |
Depth of Draw | 125mm or 100mm |
Suitable material | BOPS PP PS PVC PET PVC |
Speed (Dry run) | 20-35cycles/min |
Material Thickness Range | 0.3mm - 1.5 mm |
Sheet Width | 600mm maximum |
Material Roll Diameter | 700mm (28") Max. |
Power Supply | 3-N AC380V±15V ,50Hz |
Power Consumption | 83kw |
Air Pressure | 0.7Mpa |
Air Consumption | 0.7Mpa*1.6m³/min(Approximate) |
Machine Dimensions | 9.5m*1.5m*2.7m |
Machine Weight | 5000kg |
Certificate | ISO9001 |
fast food box
