JCL10 LED solar powered portable airfield light/runway light/taxiway light with Remote Controller and Charging port

JCL10 LED solar powered portable airfield light/runway light/taxiway light with Remote Controller and Charging port

Description

 The solar powered JCL10s is a field proven aviation light that offers enormous benefits over traditional battery and hard-wired aviation lights including low maintenance and no underground wiring.

These completely self-contained LED lights are designed to suit a range of aviation and
general applications including emergency airstrip, caution, taxiway, and threshold lighting.
The unit has two high-performance solar modules mounted within the lens, which maximize
solar collection and provide reliable operation in a range of environmental conditions.

The focal plane of the light is designed to provide a vertical divergence of between 0 and
+7 degrees, and the user-replaceable battery ensures a service life of up to 12 years.

Features:

--High quality optics for excellent beam spread control

--Ultra-light LEDs, energy saving

--Self-contained without outside power supply

--Maximum visibility distance 7.6 KM

--Once fully charged, it can work for up to 80 hours

--Auto-off after being packed for 18 hours

--All hardware of obstruction lights are made of corrosion resistant metals.

--Bird spikes for protection against droppings.

--Use of quality components and sophisticated technology reduce chances of maintenance and replacement.

--Low power consumption, which leads to huge savings on electricity bills.

--LED light source ensures long lifetime, maintenance free

--Shock and vibration resistant

--Corrosion resistant and UV stable polycarbonate housing

--Ease of mount, mount accessories available

Specifications:

 Light Characteristics:

Light Source: 18 ultra-high intensity LEDs 18 ultra-high intensity LEDs

Available colors:  Red, Green, White, Yellow, Amber, Blue, Sectored Combinations

Peak Intensity (cd):  Steady-on: Blue - 2.8     Red - 6.8     Green - 9.0      White - 7.0      Yellow - 6.5
                                    Flashing:   Blue - 5.5     Red - 18.2   Green - 21 .9   White - 19.1    Yellow - 15.1

Horizontal Output (degrees):  360

Vertical Divergence (degrees):  0 to +7

Available Flash Characteristics: >250 including steady-on (user-adjustable)

Intensity Adjustments:  Adjustable in 25% increments

LED Life Expectancy (hours): >100,000

Electrical Characteristics

Operating Voltage (V): 3.6

Temperature Range: -40 to 80°C

Solar Characteristics

Solar Module Type:  Multicrystalline

Output (watts) : 4.8 (watt)

Solar Module Efficiency(%): 17

Charging Regulation:  Microprocessor controlled

Power Supply

Battery Type:  High grade NiMH
                         – Environmentally friendly

Battery Capacity (Ah) :8

Nominal Voltage (V) :3.6

Autonomy (nights):  Steady-on: >14
                                    Flashing: >38 (14 hour darkness,12.5% duty cycle)

Radio Controlled (optional)

Frequency:  2.4GHz ISM Band Range Up to 1.4km relayed

Compliance:  FCC / CE

Physical Characteristics

Body Material:    Polycarbonate
                            – UV stabilized
Lens Diameter (mm/inches) 140 / 5½ 140 / 5½

Product Life:  Expectancy Up to 8 years

Environmental Factors:Humidity 0 to 100%

Wind Speed:  Up to 160kph

 Warranty:   2 year warranty

 Options Available:  • Radio Controlled – FCC compliant
                                • Lansin g Pilot Activated Lighting Control
                                • IR LEDs
                                • External ON/OFF Switch
                                • External Battery Charging Port
                                • Manual Operation

Applications:

--- Solar Barricade Light

---Solar Caution Light

--- Solar Taxiway Light(ICAO)

---Solar Threshold Light

---Solar Obstruction Light
