automatic cup making machine
- ningbo or shanghai port
You May Like
-
automatic cup thermoforming machine
-
clear PP lid machine
-
Plastic PP/PS/PVC/PET Material Lid Forming Machine For Oral Liquid/Solution Tray (DB-450PP)
-
DB-450PP High Quality Oral Liquid/Solution Tray Thermoforming/Making Machine For PP/PS/PVC/PET Material
-
DB-450PP Automatic PP Material Plastic McDonald's Product Thermoforming Machine
-
DB-450PP Automatic Plastic PP Materia KFC Product Thermoforming Machine
Product Details
| Condition | New | Product Type | Plastic Cup | |
| Place of Origin | Zhejiang, China | Brand Name | HENGFENG | |
| Model Number | HFTF-55T | Voltage | 380V | |
| Power(W) | 150KW | Dimension(L*W*H) | 9000x3650x3500 mm | |
| Weight | 10000kgs | Certification | CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HFTF-55T Automatic Thermoforming Machine
APPLICATION:
It is suitable for PP, HIPS, PVC and PET sheet.
HFTF-70T Title Thermoforming Machine special designed for high quality cups. Servo motor for sheet feeding and plug system. The whole line controlled by PLC. It is operates man-interface, which can works all by itself. Feeding system droved by chain and it adopt cam forming and cutting method. This is an automatic and efficient plastic cup forming machine which include feeding, heating, pulling, forming, cutting and stacking.
FEATURE:
n In-mould cutting
n High accuracy and high yield products
n Pick-up stacking system for more sanitary and save labor.
n Servo motor for plug assist and sheet feeding system.
n Two-station unwinder system.
n Rapid mould changing device.
n Mould automatic memory system.
n PLC Design with easy operation.
Main Parameter:
1,Max. Forming Area | 680*320mm |
2,Max. Forming Depth | 150 / 180 mm |
3,Sheet Thickness | 0.35—2.5mm |
4,Max. Working Speed | 35 Cycle/min |
5,Max. Clamping Force | 350 KN |
6,Heating Type | Upper / Lower Ceramic Heater |
7,Overall Dimension | 11000x3650x3500 mm |
8,Weight | About 12000 kg |
Main Specification
1- Max. Forming Area | 680×320mm |
2- Positive Forming Height | 15 mm |
3- Nagative Forming Depth | 150 / 180 mm |
4- Max. Sheet Width | 720 mm |
5- Max. Feeding Length | 350 mm |
6- Sheet Thickness | 0.35--2.5 mm |
7- Max. Roller Diameter | Φ1500 mm |
8- Air Pressure | 7 – 8.5 Bar |
9- Water Consumption | 50 L/min |
10- Air Consumption | 3000 L/min |
11- Max. Speed | 35 Cycles/min |
12- Power (Three Phase Four Wire) | 3×380V+NP+PE.50HZ |
13- Heating Oven Length | 2500 mm |
14- Upper Heating Power | 65 kw |
15- Lower Heating Power | 65 kw |
16- Main Motor Power | 11 kw |
17- Feeding Motor Power | 5 kw |
18- Scrap Rewinding Motor Power | 0.55 kw |
19- Machine Weight | 12000kg |
20- Machine Dimension | 11000x3650x3500 mm |
Item | Components | Origin |
1 | Touch Screen (10.4 Inch) | Taiwan |
2 | PLC | Panasonic, Japan |
3 | Temperature Module | Panasonic, Japan |
4 | Feeding Servo Motor | Yaskawa, Japan |
5 | Stretch Servo Motor | Yaskawa, Japan |
6 | Automatic Stacking Servo Motor | Yaskawa, Japan |
7 | Cup Push Device Servo Motor | Yaskawa, Japan |
8 | Inverter | Yaskawa, Japan |
9 | Rotary Encoder | Omron, Japan |
10 | Relay | Omron, Japan |
11 | Electromagnetic Valve | MAC, American |
12 | Button Switch | Schneider |
13 | Solid Relay | Taiwan |
14 | AC Contactor | CHNT, China |
