TIG Welder
- NINGBO/SHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | KENMAI | Model Number | TIG-250 | |
| Arc Current | 10-250 | Pulse Frequency | 50/60HZ | |
| Pilot Arc Current | 10-250 | Rated Duty Cycle | 60% | |
| Dimensions | 475*255*385 | Usage | TIG DC ARGON WELDING MACHINE | |
| Voltage | 230v | Certification | CE, ROHS | |
| Warranty | one year |
Product Description
Specifications
TIG Welder1.Save engery
2.DC argon arc welding machine
3.MOS/IGBT inverter technology
CE, ROHS
TIG Welder
1.Save engery
2.DC argon arc welding machine
3.MOS/IGBT inverter technology
TIG-250 Welder
Technical Specification
| Model Specification | TIG-250 |
| Rated input voltage(V) | 230 |
| Input capacity(KW) | 63 |
| Frequency(Hz) | 50/60 |
| No-load voltage(V) | 46 |
| Current range(A) | 10-250 |
| Output voltage(V) | 20 |
| Rated duty cycle(%) | 60 |
| Class of insulation | F |
| Case protection degree | IP21S |
| Arc-starting | HF |
| Weight(KG) | 8.5 |
| Dimension(mm) | 475*255*385 |
Main Features of TIG-250
1.Adopt with advanced MOS/IGBT inverter technology, save energy, protect the environment, light and compact, portable, accord with EMC standard.
2.Current can be adjusted stepless, high efficiency.
3.Fan-cooled, automatic protection of over-voltage and over-current, thermostatic protection, moveable welding cable.
4.Touched arc technique or HF arc-starting, be free from electromagnetisms disturb, no slag, smooth welding line.
5.Argon, suit for stainless steel, copper, aluminum, steel, titanium, nickel and other alloy material.
6.With complete accessories.
7.Carton box
TIG Welder
