China Made Pit Type Industrial Annealing Heat Treatment Electric Furnace for Sale
- Any port of China.
- T/T
You May Like
-
Professional Manufacture Pit Type Ring Furnace
-
Pit Heating Treatment Electric Furnace for Cement Nail
-
Pit Quenching/Hardening Furnace Used for Standard Parts, Bearings, Chains, Screws, Needles,etc
-
Long Axis / Shaft / Gear Quenching/Hardening Industrial Electric Furnace
-
Best Price for Pit Type Electric Tempering Furnace
-
Low Energy Consumption Well Batch-Type Steel Tempering Resistance Furnace
Product Details
| Condition | New | Type | Resistance Furnace | |
| Usage | Heat Treatment Furnace | Place of Origin | Henan, China | |
| Brand Name | ZHONGLI | Model Number | RJ2-90-9 | |
| Voltage | 380V,also can provide as user's needs. | Power(W) | 90kw | |
| Dimension(L*W*H) | diameter:1200mm; depth:1400mm | Weight | 3600kg | |
| Certification | ISO9001:2008 | Warranty | 1 year | |
| After-sales Service Provided | No overseas service provided |
Product Description
Pit type industrial annealing heat treatment electric furnace
Brief
RJ2 series pit type industrial annealing heat treatment electric furnace is energy-saving batch type heat treatment furnace, can be used for stainless steel wire, carbon steel belt and wire, wire rod, copper wire, coiler and slender axies metal parts for non oxidation or bright annealing heat treatment, keep the workpiece clean and tidy after annealing, mainly used for small batch workpiece heat treatment.
Structure
Pit type furnace is composed of furnace shell, lining, heating device and temperature control and other major parts, furnace body is cylindrical deep well, workpiece is installed vertically furnace inside for heating, Pit type furnace is usually placed under the ground plane in the workshop, also is placed above the ground plane, or ground level fluctuation in each half.
Pit type furnace can also be used for mechanical parts for tempering ,annealing, normalizing, carburizing and carbonitriding heat treatment, etc, electricity or gas can be used for heating, with electricity as heat source, is called the pit type resistance furnace,can form a complete set of heat treatment production line with pit type tempering furnace, quenching tank, washing machine and other equipment.
Main technical parameters
Name | Model | ||||||||
RJ2-60-9 | RJ2-75-9 | RJ2-90-9 | RJ2-125-9 | RJ2-140-9 | RJ2-190-9 | RJ2-240-9 | |||
Rated power(kw) | 60 | 75 | 90 | 125 | 140 | 190 | 240 | ||
Rated voltage(V) | 380 | ||||||||
Frequency(Hz) | 50 | ||||||||
Phase | 3 | ||||||||
Max.temperature(℃) | 950 | ||||||||
Working temperature(℃) | 650-950 | ||||||||
Furnace hearth size(mm) | Diameter | φ800 | φ950 | φ1000 | φ800 | φ1000 | φ1000 | φ800 | |
Depth | 1000 | 1400 | 1200 | 3000 | 2400 | 3600 | 5500 | ||
Heating zone | 1 | 1 | 1 | 3 | 2 | 3 | 4 | ||
Heating element connection | YY | YY | YY | YY | YY | YY | YY | ||
No-load heating up time(h) | 3 | 3 | 4 | 4 | 4 | 4 | 4 | ||
Temperature control precision(℃) | ±1 | ||||||||
Furnace temperature uniformity(℃) | ±5-8 | ||||||||
Max loading capacity(kg) | 800 | 1100 | 1500 | 2400 | 3000 | 4500 | 6500 | ||
Weight(kg) | 2400 | 4900 | 3600 | 4800 | 5200 | 6400 | 12000 | ||
Note: Various size pit type annealing furnace can be designed and manufactured as user's needs.
.
