phocos high efficency solar charge controller

FOB Price

Negotiable / Piece

100 Pieces(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port qingdao

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	Phocos
Model Number	CML08	Specification	Normal
Application	Commercial

Product Description

Specifications

Solar Charge Controller
1.Brand name: Phocos
2.Battery charging with 3LEDS
3.12/24V auto detection
4.PWM-regulation

Phocos CML08 solar charge controller

Feature:

•Battery State-of-Charge display with 3LEDS

•Acoustic load disconnect pre-warning

•PWM-regulation (series type)

•Boost, Equalize and Float charging, also for VRLA

•Automatic 12/24V detection

•Integrated temperature compensation

•Large terminals (up to 16 mm wire size)

•SOC and voltage controlled LVD

•Fully electronically protected

The CML series is a sophisticated solar charge controller family for low cost applications. The electronic circuit is equipped with a microcontroller that provides high- efficiency charging technology together with a number of outstanding status display, warning and safety functions. The temperature-compensated three-stage PWM charging method (boost-equalization-float) is now adjustable to sealed and vented lead-acid batteries. The new version also allows an either SOC or voltage controlled low voltage disconnect function. The battery status is clearly indicated by three LEDs. As the first controller on the market in this price range it comes with an acoustic low voltage load disconnect pre- warning feature

TYPE	CML 05	CML08	CML10	CML15	CML20
System voltage	12/24 V auto recognition
Max. charge/load current	5A	8A	10A	15A	20A
Float charge	13.7/27.4 V (25 °C)
Boost charge	14.4 /28.8V (25 °C), 2 Std. activation: battery voltage < 12.3/24.6 V
Equalization	14.8/29.6 V (25 °C), 2 Std. activation: battery voltage < 12.1/24.2 V
Deep discharge protection:
State of charge dependent	11.4-11.9 V/ 22.8- 23.8 V
Voltage dependent	11.0/22.0 V
Reconnect level	12.8/25.6 V
Overvoltage protection	15.5/31.0 V
Undervoltage protection	10.5/21.0 V
Max. panel voltage	30 V in 12 V system
(Overvoltage protection by varistor)	50 V in 24 V system
Temperature compensation	−25 mV/K at 12V
(Charge voltage)	−50 mV/K at 24V
Max. self consumption	< 4 mA
Grounding	positive grounding possible
Ambient temperature	−40 to +50 °C
Max. height	4,000 m above sea level
Battery type	lead acid (GEL, AGM, flooded)
Wire cross section	< 16 mm2
Weight	160 g
Dimensions (W x H x D)	80 x 100 x 32 mm
Type of protection	IP22
