Home > Products > Box type furnace > High Quality Box Type Gas Quenching Vacuum Furnace
High Quality Box Type Gas Quenching Vacuum Furnace
- Any port of China
- T/T
You May Like
-
High Efficiency Box Type Vacuum Case Hardening Furnace
-
RX3 Series Box-type Electric Furnace for 1200 Degree
-
1300 Degree Chamber Type Vacuum Electric Heat Furnaces
-
RX3 Series Industrial Electric Chamber Furnace
-
Batch-type Box Protective Atmosphere Hardening Industrual Furnace
-
Manufacturer Provide Box Batch-Type Protective AtmosphereVacuum Quenching Resistance Furnace
Product Details
| Condition | New | Type | Resistance Furnace | |
| Usage | Heat Treatment Furnace | Place of Origin | Henan, China | |
| Brand Name | ZHONGLI | Model Number | RX3-75-9 | |
| Voltage | 380V,also can provide as user's needs. | Power(W) | 75kw | |
| Dimension(L*W*H) | 2000mm*1100mm*750mm | Weight | 5200kg | |
| Certification | ISO9001:2008 | Warranty | 1 year | |
| After-sales Service Provided | No overseas service provided |
Product Description
Box type gas quenching vacuum furnace
Brief
RX3 series box type gas quenching vacuum furnace is standard energy-saving batch type furnace,using the following heat treatment processes: quenching, tempering, annealing and normalizing heat treatment,etc.
Application field
Mainly used for high chromium, high manganese steel castings, ductile iron, roll, steel ball, crusher hammers, wearing plate, flange and various mechanical parts. Can also suitable formetallic material heat treatment in various colleges, universities and research institutes.
Advantages
1.Low heat conduction and heat capacity;
2.Excellent thermal stability and thermal insulation;
3.Good heat preservation effect and temperature uniformity.
Main technical parameters
Model | Rated power(KW) | Rated voltage (V) | Rated temperature(℃) | Phase | Furace hearth size(L*W*H)(mm) | Max.loading capacity(kg) | Weight (kg) |
RX3-15-9 | 15 | 380 | 950 | 3 | 650*300*250 | 80 | 1100 |
RX3-30-9 | 30 | 380 | 950 | 3 | 950*450*350 | 200 | 2000 |
RX3-45-9 | 45 | 380 | 950 | 3 | 1200*600*400 | 400 | 2500 |
RX3-60-9 | 60 | 380 | 950 | 3 | 1500*750*450 | 700 | 4500 |
RX3-75-9 | 75 | 380 | 950 | 3 | 1800*900*550 | 1200 | 5200 |
RX3-20-12 | 20 | 380 | 1200 | 3 | 650*300*250 | 50 | 1400 |
RX3-45-12 | 45 | 380 | 1200 | 3 | 950*450*350 | 100 | 2210 |
RX3-65-12 | 65 | 380 | 1200 | 3 | 1200*600*400 | 200 | 2600 |
RX3-90-12 | 90 | 380 | 1200 | 3 | 1500*750*450 | 400 | 3900 |
RX3-115-12 | 115 | 380 | 1200 | 3 | 1800*900*550 | 600 | 4900 |
RX3-14-13 | 14 | 380 | 1350 | 3 | 520*220*220 | 50 | 635 |
RX3-25-13 | 25 | 380 | 1350 | 3 | 600*280*300 | 80 | 1200 |
RX3-37-13 | 37 | 380 | 1350 | 3 | 810*550*370 | 100 | 1920 |
Remarks:Various furnace sizes can be designed and manufactured as user’s needs.
