2.1 Mage Pixel Best HD Camera With DSY Interface CMOS Sensor

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1. Best hd camera
2. 2.1 Megapixel
3. Equipped with 20x optical zoom lens
4. Natural and smooth video image

2.1 Mage Pixel DSY Interface CMOS Sensor Best HD Camera

Product Description

Features:

Performance:

Dimension:

Installation:

Our Services

video conference camera specifications:

Model No.		HD820-DSY-SN6300
Image Sensor	Image Sensor	1/2.9" CMOS
	Effective Pix	2.1 Megapixel
	Min. Illumination	0.5Lux at F1.6
	White balance	Auto/Manual
	Gain control	Auto/Manual
	Backlight compensation	On/Off
	Shutter speed	1/1 - 1/10,000S
	S/N ratio	>50db
Lens	Focus	f=4.7-94mmF1.6-2.8
	Iris	Auto/Manual
	Lens	20 Optical zoom
	Horizontal view angle	55.4
Video output		HDMI, HD-SDI, DVI , YPbPr, CVBS
Signal system		1080P@30,1080P@25, 1080i@60,1080i@50, 720P@60,720P@50 ,720P@30, 720P@25 ,PAL ,NTSC
Control terminal		EIA/RS232C,EIA/RS485(Bidirectional)
Control Protocol		VISCA,PELCO-D
baud rate		9600/38400bps
patrol line		4 cruise sequence
preset position		64 preset positions
Speed Match		Pan/Tilt movement speed depends on camera module zoom in/out
OSD Menu		Access to OSD Menu and adjust camera module parameters
Image auto flip		Support Horizontal/Vertical image flip
Pan movement speed		1-200 degree/Second
Tilt movement speed		1-150 degree/Second
Pan movement range		Pan: 0-355 degree
Tilt movement range		Up: 45 degree, Down: 45 degree
Pan scanning automatically		Support Pan scanning automatically
Boundary scanning		0-355 degree (programmable)
Remote controller		IR Wireless Remote controller P/T/Z
Power supply		DC12V,2A
Work Temperature		0-50 degree
Humidity		0-95%RH
LxWxH		250mm x 140mm x 154mm
Weight		1380g

Accessories kits in package:
