motion sensor video conference camera(HD820-U3-K3)

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1. Best camera for video conference camera.
2. USB 3.0 Interface.
3. High Definition PTZ camera.
4. Work & Standby LED.

The best motion sensor video conference camera ——HD820

Model No.		HD820-U30-SN6300
Image Sensor	Image Sensor	1/2.8" Type Exmor CMOS
	Effective Pix	3.27 Megapixel
	Min. Illumination	0.1Lux
	White balance	Auto/Manual
	Gain control	Auto/Manual
	Backlight compensation	On/Off
	Shutter speed	1/1 - 1/10,000S
	S/N ratio	>50db
Lens	Focus	f=4.7-90mmF1.6-3.5
	Iris	Auto/Manual
	Lens	20 Optical x 12 digital zoom
	Horizontal view angle	55.4
Video output		USB 3.0
Signal system		1080P@30,1080P@25, 1080i@60,1080i@50, 720P@60,720P@50 ,720P@30, 720P@25 ,PAL ,NTSC
Control terminal		EIA/RS232C,EIA/RS485(Bidirectional)
Control Protocol		VISCA,PELCO-D
baud rate		9600/38400bps
patrol line		4 cruise sequence
preset position		64 preset positions
Speed Match		Pan/Tilt movement speed depends on camera module zoom in/out
OSD Menu		Access to OSD Menu and adjust camera module parameters
Image auto flip		Support Horizontal/Vertical image flip
Pan movement speed		1-200°/Second
Tilt movement speed		1-150°/Second
Pan movement range		Pan: 0-355°
Tilt movement range		Up: 45°, Down: 45°
Pan scanning automatically		Support Pan scanning automatically
Boundary scanning		0-355°(programmable)
Remote controller		IR Wireless Remote controller P/T/Z
Power supply		DC12V,2A
Work Temperature		0-50°C
Humidity		0-95%RH
size		250mm x 140mm x 154mm
Weight		1380g

Accessories kits in package:

1x HD 820 Video Camera

1x DC 12V/2A Power Adaptor

1x User’s manual

1x3m USB 3.0 Cable

1x Installation brackets & screws

1xIR Remote Controller
