Home > Products > High frequency welding and cutting machines > 8kw Welding & Cutting Machine Automatic Toothbrush Blister Packing Machine
8kw Welding & Cutting Machine Automatic Toothbrush Blister Packing Machine
- shenzhen
- T/T Credit Card PayPal
You May Like
-
Rotary Style 25kw Automatic Toothbrush Blister Packing Machine
-
Slide Plate Soft PET Creasing Automatic Pvc Chocolate Box Machine
-
Auto Slide Plate 12kw HF Automatic Blister Packing Machine
-
PLC Panel High Frequency Automatic Blister Packaging Machine
-
Slide Plate PET/PVC Plastic Box Folding and Creasing Machine
-
High Frequency Automatic PET Gift Box Making Machine
Product Details
| Condition | New | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Pneumatic | |
| Voltage | 380v | Power | 8kw | |
| Place of Origin | China | Brand Name | Sinopwr | |
| Model Number | ZG-8KWET | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
8kw welding & cutting machine automatic toothbrush blister packing machine
1.Adopt splitting device by motor,which the working position can be rotating alternating work.
2.3-5 working positions available, which also can be matched with robot instead of labor feeding or removing material.
3.Equipped with oil pressure supercharging device make the output larger, also finishing the whole process with welding and cutting scraps one-time.
4.American NL-5557 sparkle protector device, which make the mold & products to minimize the damage degree.
5.Adopt Europe type high frequency coaxial resonators when current overloaded then automatically cut off the pressure to protect the oscillation tubes and rectifier.
6.Custom size work tables and welding platen is available
Application:
Used for APET,PETG,PVC,PET,etc material usage of double blister sealing, blister paper card packing, toothbrush packing, with EVA cloth leather, leather,PU material welding and fusing,also be used in PVC, APET, PETG, PP sheet of soft crease box production line (SK)
Specifications:
| Model | ZG-10KW-4ACJ | ZG-12KW-4ACJ | ZG-15KW-4ACJ |
| Power | 10KW | 12KW | 15KW |
| Voltage | 50/60HZ AC380V 3P | ||
| Frequency | 27.12MHz | ||
| Input power | 18KVA | 20KVA | 25KVA |
| Rectifier | silicon diode | ||
| Oscillation tube | E3069RB | E3130RB | 8T85RB |
| Max pressure | 500kg | 800kg | 1000kg |
| Operation mode | pneumatic | ||
| Max distance of electrodes | 200mm | ||
| Press stoke | 150mm | ||
| The size of upper electrode | 300*500mm | 400*500mm | 400*600mm |
| The size of lower electrode | 300*500mm | 400*500mm | 400*600mm |
| The range of temperature | 30~200 oC adjustable | ||
| Welding time | 0---10sdjustable | ||
| Productivity | < 4000times/8hours | ||
FAQ:
1,How to install the machine?
2,How do I use the machine ?
3,How to set operating Mold and machine maintance?
4,Machine configuration
5,Troublesolving
