Rotary Style PVC 8kw High Frequency Welding Machine
- shenzhen
- T/T
You May Like
-
Rotary Plastic PVC PET Square Crease Box Forming Machine
-
Rotary Blister Battery HF Plastic Welding Machine
-
Automatic PVC PET Plastic Creasing Box Making Machine
-
Semi Automatic Push Platform Single Head High Frequency Medicine Bag Welding Machine
-
PVC PET Plastic Box 25KW High Frequency Machine
-
8kw Rotary Bicycle LED Blister Packaging Welding Machine
Product Details
| Condition | New | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Pneumatic | |
| Voltage | 380v | Power | 8kw | |
| Place of Origin | Guangdong, China | Brand Name | Sinopwr | |
| Model Number | ZG-8KWET | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Rotary Style PVC 8kw high frequency welding machine
Features:
1.Adopt splitting device by motor,which the working position can be rotating alternating work.
2.3-5 working positions available, which also can be matched with robot instead of labor feeding or removing material.
3.Equipped with oil pressure supercharging device make the output larger, also finishing the whole process with welding and cutting scraps one-time.
4.American NL-5557 sparkle protector device, which make the mold & products to minimize the damage degree.
5.Adopt Europe type high frequency coaxial resonators when current overloaded then automatically cut off the pressure to protect the oscillation tubes and rectifier.
6.Custom size work tables and welding platen is available
Application:
Used for APET,PETG,PVC,PET,etc material usage of double blister sealing, blister paper card packing, toothbrush packing, with EVA cloth leather, leather,PU material welding and fusing,also be used in PVC, APET, PETG, PP sheet of soft crease box production line (SK)
Specifications:
| Model | ZG-10KW-4ACJ | ZG-12KW-4ACJ | ZG-15KW-4ACJ |
| Power | 10KW | 12KW | 15KW |
| Voltage | 50/60HZ AC380V 3P | ||
| Frequency | 27.12MHz | ||
| Input power | 18KVA | 20KVA | 25KVA |
| Rectifier | silicon diode | ||
| Oscillation tube | E3069RB | E3130RB | 8T85RB |
| Max pressure | 500kg | 800kg | 1000kg |
| Operation mode | pneumatic | ||
| Max distance of electrodes | 200mm | ||
| Press stoke | 150mm | ||
| The size of upper electrode | 300*500mm | 400*500mm | 400*600mm |
| The size of lower electrode | 300*500mm | 400*500mm | 400*600mm |
| The range of temperature | 30~200 oC adjustable | ||
| Welding time | 0---10sdjustable | ||
| Productivity | < 4000times/8hours | ||
FAQ:
1,How to install the machine?
2,How do I use the machine ?
3,How to set operating Mold and machine maintance?
4,Machine configuration
5,Troublesolving
