Range

Resolution

Accuracy

Max. open Circuit Voltage

Max. Short Circuit Current

Overload Protection

40Ω

0.01Ω

1%+30

12.8V

>200mA

600Vrms

Range

Resolution

Beeper Active

Max. open Circuit Voltage

Overload Protection

0.01Ω

Resistance<4Ω

12.8V

600Vrms

Range

Resolution

Accuracy (above 1V)

Input Impedance

Overload Protection

600V

0.1V

1.5%+3

4.5MΩ

750Vrms

Range

Resolution

Accuracy

Terminal Voltage

4MΩ/40MΩ/400MΩ/4000MΩ/250V

1K

3%+5
(<2000M)

5%+5
(>2000M)

250V+20% ~ -0%

4MΩ/40MΩ/400MΩ/4000MΩ/500V

500V+20% ~ -0%

4MΩ/40MΩ/400MΩ/4000MΩ/1000V

1000V+10% ~ -0%

Range

Test Current

Short circuit current

4000MΩ/250V

1mA

250KΩ (load)

<1.5mA

4000MΩ/500V

500KΩ (load)

4000MΩ/1000V

1MΩ (load)

Display

80 x 50mm Big LCD penal with 50 segments analog display Max Reading 4000

Over range Indication

“OL” will be shown on the LCD penal when out of range measurement is made.

Low Battery Indication

The  will be shown when the battery need to be changed

Sampling Rate

2.5 times/sec Digital Display
10 times/sec Bar Graph

Power Source

Eight 1.5Volt AA size Battery

Operating Temperature and Humidity

0℃ to 40℃ (32℉ to 104℉ ), below 80% RH

Storage Temperature

-10℃ to 60℃ (14℉ to 140℉ )

Dimension

190(L)x140(W)x77(H)mm

Weight

Approx. 900g (with battery)

Accessories

Test Lead, Battery, Instruction Manual
