S type load cell for force measuring system (50lb~10klb)
- 10000 Piece / Pieces per Month
- shanghai
- T/T Credit Card PayPal
You May Like
-
china S type weighing transducer load cellload cell 1000kg
Quality Choice
-
supplier S Type compression and tension load cell Sensor(2t,3t,5t)
-
china supplier alloy steel S-type load cell (5kg~20t)
Quality Choice
-
Weighing Sensor S Type (15~30t) Load Cell (TSK)
-
Stainless Steel S type loadcell(TSK) for batching and weighing scale
-
15t High accuracy S-type load cell(TSK)
Product Details
| Place of Origin | Jiangsu, China | Brand Name | SILVANUS | |
| Model Number | TSD | Usage | Pressure Sensor | |
| Theory | Resistance Sensor | Output | Analog Sensor |
Product Description
S Type Load Cell (TSD)(50lb~10klb)
Load Cell (TSD) Features
1.S type load cell , tension and compression
2.Good output symmetry , compact structure , simple to install , full range of capacities
3. Suitable for electromechanical scale , crane scale ,hopper scale and
4.various special scales
Load Cell (TSD) Application
Apply to electronic hook scales and various special weighing apparatus
Load Cell (TSD) Dimensions(mm)
Load Cell (TSD) Specifications
Emax(Max. capacity) | lb | 50~10k | |
Sensitivity | mV/V | 3.0±0.002 | |
Accuracy class |
| C2 | C3 |
Maximum number of verification intervals | nmax | 2000 | 3000 |
Minimum load cell verification interval | Vmin | Emax/5000 | Emax/10000 |
Combined error | %F.S | ≤±0.030 | ≤±0.020 |
Creep | %F.S/30min | ≤±0.024 | ≤±0.016 |
Temperature effect on sensitivity | %F.S/10°C | ≤±0.17 | ≤±0.011 |
Temperature effect on zero | %F.S/10°C | ≤±0.023 | ≤±0.015 |
Zero balance | %F.S | ±1.0 | |
Input resistance | Ω | 380±20Ω | |
Output resistance | Ω | 352±3Ω | |
Service temperature range | °C | -30...+70 | |
Safe overload | %F.S | 120 | |
Ultimate overload | %F.S | 200 | |
Recommended excitation voltage | V | 5…15 | |
Insulation resistance | MΩ/50V | >5000 | |
Protection class |
| IP67/IP68 | |
Load cell material |
| alloy steel/stainless steel | |
Cable length | m | 5 | |
Cable outer caliber | mm | Φ5 | |
Packaging & Delivery
Delivery Usually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
LETTER OF PATENT:
Transportation | Routine |
| By car | 3 hours from Shanghai to Yixing |
| By high speed railway | 2 hour from Shanghai(or Shanghai Hongqiao) railway station to YiXing railway station,then we will pick you up.It will take 10 mins by car from Yixing railway station to our company. |
