XCMG WZ30-25 Mini Cheap Backhoe Loader
- Shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Brand Name | XCMG | |
| Model Number | WZ30-25 | Place of Origin | Jiangsu, China | |
| Type | Backhoe Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 5900*2300*3450mm | Certification | ISO9001,CE | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
XCMG WZ30-25 Mini Cheap Backhoe Loader
Backhoe Loader WZ30-25
synchronization shift, electric-hydraulic control
braking axle
Main Technical Parameters:
Item | Unit | Parameter | |||
Backhoe bucket capacity | m3 | 0.3 | |||
Rated loading bucket capacity | m3 | 1 | |||
Rated Lifting Force | KN | 25 | |||
Engines rated power/rated speed | KW/r/min | 70/2200 | |||
Total operating weight | kg | 7400 | |||
Backhoe turning angle | Left | º | 90 | ||
Right | º | 90 | |||
Backhoe parameter | Max. digging radius | mm | 5150 | ||
Max. dump height | mm | 3738 | |||
Radius at the max. dump height | mm | 1084 | |||
Max. digging radius at ground level | mm | 5105 | |||
Digging buckets max. rotating angle | º | 180 | |||
Max. digging depth | mm | 4340 | |||
Max. digging force | KN | >50 | |||
Loading parameter | Max. dump height | mm | 2612 | ||
Dump reach at max. dump height | mm | 727 | |||
Bucket drawback angle | Transportation position | º | 43 | ||
Ground position | º | 34 | |||
Dump angle | º | 43.5 | |||
Digging depth | mm | 191 | |||
Max. breakout force | KN | >40 | |||
Max. grade ability | % | 16.7 | |||
Max. traction power | KN | 70 | |||
Gear and travel speed | Forward/Backward gear I | km/h | 5.9/5.9 | ||
Forward/Backward gear Ⅱ | 9.8/9.8 | ||||
Forward/Backward gear Ⅲ | 21.2/21.2 | ||||
Forward/Backward gear IV | 39.8/39.8 | ||||
Min. turning radius | mm | 3795 | |||
Total length | mm | 7077 | |||
Total height (Cab) | mm | 2700 | |||
Max. height for transportation | mm | 3424 | |||
Total Width | mm | 2350 | |||
Bucket width | mm | 2315 | |||
