PROMAX GV-898 Multistandard TV Signal Generators

• Color system: PAL, NTSC and SECAM

• Transmission standards B,G, I, D, K, L, M, N

• Composite video output: 1 Vpp (75 W)

• Adjustable synthesized RF output from 32 to 900 MHz

• DSB or VSB modulation, with progressive attenuation in 1 dB steps

• 22 test patterns 4:3 and 16:9 format

• Outputs: BLACKBURST (PAL and NTSC), RGB, SCART, S-VHS, synchronisms, vertical and horizontal pulses, fixed tones at 1 kHz and 3 kHz

• Inputs: left and right channels sound for Zweiton modulation, video

• Selectable mono multi-standard sound. Stereo/dual Zweiton sound in B, G, D, K, M formats and NICAM sound in B, G, I, L formats

• 99 configuration memories

• Available signals: VITS (Video Interval Test Signals), WSS (Wide Screen Signaling) in 8 formats, FLOP-TELETEXT, VPS and PDC

 Packing:

• Carton packing
• Pack the instrument with PE bubble bag
• Foam-in-place to protect the instrument
• Fasten the carton with Belt
• Pack the carton with PE film to waterproof

•  30days warranty, No ROR
•  During the warranty date, the buyer can return the item if have quality problem.
• If you want to return the instruments, the return item has to be the original packing. Without my permission, the instrument cannot be dismantled.
• You are responsible for returning the item and paying for return shipping. The payment for the freight cost will not return. Only payment for the instrument will be refund.
• The refund will complete within 7 working days after we receive the return items
