Heat Resistance Leak Seal Rescue Repair Silicone Seal Seamless Tape

It is for the repair of cabling.ready to use with a high temperature range. Can be used on primary cable insulation where class H temperatures are present.Self fusing and seamless.Immediately waterproof, and featuring revolutionary 'adhesive-free' technology. It is of uniform thickness and is ideal for applications, where a smooth, even layer of tape is not required. , which also meet various military and aerospace specifications, are also available.

TYPICAL PROPERTIES
Thermal Stability ....................................356°F/180°C
Temperature Range ............................-65°F to +500°F (-50°C to +260°C)
Volume Resistivity.................................. 1013 ohm-cm min. (ASTM D257)
Self Adhesion ............................................2 p.p.i min. (ASTMD2148)
Hardness ........................................................50±10 Shore A (ASTM D2240)
Moisture Absorption ..........................0.9% (46 hrs. in H2O @ 70°F)
NOTE: The above properties are published as a guide only, and should not be
used for specifications without testing in your own laboratory.

PERFORMANCE ADVANTAGES
• Resists moisture, oxygen, and ozone to assure continuous high insulation values.
• Conforms smoothly when wrapped around complex forms.
• Bonds to itself at room temperature within 24 hours.
• Remains non-tacky to the touch and does not adhere to other surfaces, or substrates.
• Insulates with single wrap, thereby reducing labor time and cost.
• Dampens vibration and resists heat and mechanical shock as well as corona.
• Inherently flame retardant and when burned forms a non-conductive ash. Meets the horizontal burn test criteria prescribed in FAR 25.853.
• SA & SB MOX-Tapes® provide a uniform thickness even around sharp edges. Fiberglass fabric, encapsulated inside the silicone rubber, prevents wicking and maintains high insulation resistance under high humidity conditions. These
controlled stretch tapes provide a uniform insulation barrier.
• All tapes are protected by a special interleaved liner.

APPLICATIONS

Mechanical
• Protection of coils from vibration.
• Vibration fixture, anti-scratch, and clamping pads.
• Harness wrapping and wire bundling, including for high temperature applications.
• Applied to rollers for protection and traction.
• Plant maintenance.
• Superior, heavy duty repair tape for emergency insulating barrie
Electrical
• Insulation of field armature and interpole coils in large motors.
• Insulation for splicing and terminating of wire and cable.
• Insulating and sealing electrical connections.
• Insulating coil leads and bus bar connections.
• Electromagnetic coil insulation.
• Motor connections.
• Overwrapping of deteriorated insulation in reclaimed motors.
Environmental
• On-board aviation and space applications.
• Underground cable splices.
• Insulating heated transfer lines.
• Insulating in radioactive environments.
• Masking agent utilized in manufacturing processes and powder coatings.
• Insulating, protecting, and sealing rigging hardware and power systems in marine applications.
