hidden camera with voice recorder very small Low illumination

Specifications

Introducing the high resolution 720*480/640x480/720p/1080p 4GB~32GB hidden camera. The Ideal tool for "body worn" instant covert video recording. "One Touch" record button activates the camcorder for up to two hours recording on a single charge. Recordings can be later downloaded via high speed USB 2.0 to your PC for viewing and storing. Includes RF remote control for operating the unit without detection.

* Accessories:  1* shoe , 1* USB Power Adapter, 1* USB Cable , 1* User Manual - English

 Product Introduction

This product is the first with high-definition digital video camera, camera, sound recording, voice control, motion detection camera DVR, easy operation, remote operation can be used in a dark environment, beautiful and practical, easy to carry features, is business, education, security, media, justice, tourism, health care, utilities and other fields of life, favored by the majority of users.

Instructions

1.1) Power: the power switch to the ON position, press the power button for 2 seconds the machine boot (hold down the remote control ON / OFF button is also operational), the yellow light equipment into standby, LCD screen displays the time. Long press the power button for 5 seconds (hold down the remote control ON / OFF button is also operational), yellow and blue lights flash twice to complete shutdown, shutdown plug the power switch to the OFF position, if the device is not turned on insert TF card, yellow and blue lights flashing.

2)Voice recording: In standby mode click the voice button (in the voice-activated remote control keys are operational), blue light flashes 5 times then turns off, the yellow light is also out, LCD screen displays the current time, equipment, access to voice standby mode, when the outside world sound 65 decibels or more, the machine automatically enters video mode, continuous video 3 minutes to save and enter the voice standby mode, if the external sound of 65 decibels or more, once again, the machine continued to re-enter the video mode video 3 minutes to stop and save again and again. Click the Voice button to save the current video file and exit the voice state machine into standby, the yellow light.

3)Motion Detection button: In standby mode button click motion detection (motion detection by remote control keys are operable), blue light flashes 5 times then turns off, the yellow light is also out, LCD screen displays the current time, equipment access motion detection standby, when outsiders move objects automatically after 3 minutes video motion detection to save and enter standby mode again and again. Short keys by motion detection, motion detection mode and out of video files into the machine saving standby, the yellow light..

4)Video: Under standby mode, long press the function key for 2 seconds, the yellow light flashes three times to light off, start video and press the function key to stop video recording, the yellow light on and saving a *. AVI format video file.

5)Photo: In standby mode click camera / recording button to enter the camera (the remote control of camera / recording button is also operational), long after the yellow light flashed on, store documents into standby.

6)Recording: In standby mode, press and camera / recording key to the studio (by remote control camera / recording button is also operational), blue light flashes 5 times then turns off, the yellow light at the same time off, do not change the screen display (display time ). Short press camera / recording button, exit recording mode and save the current recording file into the machine standby, the yellow light.

7)Infrared night vision switching: the implementation of video in standby or press the power button action point in time to open the night lights (hold down the remote control ON / OFF button are operable), can take pictures in dark environments or video, while blue lights ; then click the power button shut down night vision light, and blue light off.

8)Playback or delete mode: In standby mode click the playback button, the screen shows the corresponding folder, press the UP DOWN keys to select the appropriate Or folder, click the start button to confirm and to enter, press UP Or DOWN key to select the appropriate file, Click the start button may be the play or pause; If you want to delete this file, click the Motion Detection button to enter delete mode, press the UP or DOWN may choose to delete individual or all of the files, click the start button to confirm the deletion, click mobile surveillance test button to enter playback mode exit delete mode, in playback mode, click the Playback button to exit and enter the standby mode, the screen displays the time, a long bright yellow.

9) Time setting: In standby mode press and playback button for 2 seconds, time can be set, according to UP or DOWN changes to minutes and seconds can be, click start button to confirm.

10) Low power: If it detects that the battery is low, yellow and blue lights flash 2 times after the shutdown, the shutdown will save the current of the pre-recorded file.

11)Charge: Connect the device to a computer or power adapter for charging, charging, dual-lamp light, full of destruction after the dual-lamp.

12)File Storage: In the shutdown state, use the USB data cable to connect the device to the computer, the recorded images can be copied or cut to play computer.

     Note: The device is a U disk into the computer shutdown.

13)PC camera function: This device can be used as PC camera, driver software to be installed before use, the device is turned on to connect with the computer, the computer will appear on a standard video equipment, then equipment can be used when the camera head.

     Note: The device connected to the computer after the boot when the camera can be used.

     Guaranteed 99% yield when the ship reaches the hands of the buyer.

Package Content:

* 1 x hidden Camera

DHL UPS
