Planetary Speed Reducer for Sun tracker of Solar PV Power Station
- Shanghai
- T/T
You May Like
Product Details
| Gearing Arrangement | Planetary | Place of Origin | Anhui, China | |
| Brand Name | Bolin |
Product Description
Specifications
1. Planetary speed reducer2. Fine Reducer for Sun tracker of Solar PV Power Station
Our company has great strength in R&D of planetary speed reducer, our technology partner is Hefei Industry University. We have many advanced testers such as service life tester, mechanical efficiency tester, noise measurement system to guarantee the quality.
The advantage of our planetary speed reducer:
- Good sealing, level: IP65. Dustproof, waterproof, No oil leakage.
- Small backlash less than 2 degree.
- High mechanical efficiency as to 76%.
- Consistent in quality and competitive price
Solar power station project is great benefit for human being. Most of our planetary speed reducer could be used for solar field, such as: solar tracker, solar tracking, solar power station, solar panels etc. Now, we have following specifications: 45mm, 59mm, 92mm, which are mainly applied in solar power field. Please contact with me for more information.
| Regular Product List of Planetary Speed Reducer for Sun tracker of Solar PV Power Station | |||||||
| Series | OD of reducer (mm) | In-house No | I/O Speed Ratio | Output Speed | Rated Torque (N.m) | Noise (db) | Weight (g) |
| 45 | 42 | F1016 | 223 | 12 | 50 | 42 | 495 |
| 45 | 42 | F1042 | 223 | 12 | 50 | 42 | 482 |
| 45 | 42 | F1102 | 257 | 11 | 50 | 40 | 481 |
| 45 | 42 | F1082 | 223 | 12 | 50 | 42 | 482 |
| 45 | 42 | F1098 | 167 | 17 | 20 | 40 | 393 |
| 45 | 42 | F1101 | 132 | 2 | 30 | 42 | 340 |
| 59 | 56 | F1011 | 232 | 12 | 100 | 50 | 998 |
| 59 | 56 | F1013 | 232 | 12 | 100 | 50 | 992 |
| 59 | 56 | F1014 | 232 | 12 | 100 | 50 | 992 |
| 59 | 56 | F1026 | 1972 | 7 | 100 | 50 | 1609 |
| 59 | 56 | F1061 | 232 | 12 | 120 | 50 | 992 |
| 59 | 59 | F1104 | 15 | 735 | 15 | 60 | 786 |
| 59 | 59 | F1105 | 4 | 1250 | 15 | 60 | 786 |
| 81 | 81 | F1052 | 236 | 12 | 200 | 55 | 2450 |
| 81 | 81 | F1077 | 16 | 2 | 200 | 55 | 2000 |
| 81 | 81 | F1080 | 180 | 3 | 200 | 55 | 2559 |
| 92 | 92 | F1086 | 246 | 12 | 230 | 58 | 5559 |
| 92 | 92 | F1087 | 445 | 6 | 330 | 58 | 3400 |
| 92 | 92 | F1088 | 384 | 7 | 330 | 58 | 3400 |
