Home > Products > Medium Voltage Wall Through Bushing > 12kV Epoxy Resin Bushing
12kV Epoxy Resin Bushing
US$ 12 - 15
/ Piece
100 Pieces(Min. Order)
- Shanghai
- T/T Credit Card PayPal
You May Like
-
40.5kV Screen Bushings for KYN61-40.5 Switchgear
-
12kV Epoxy Resin Cast Bushing
-
Screen Busbar Bushing for 35kV EATON Switchgear
-
Screen Bushing With 2,500A Rated Current, Suitable for 35kV Switchgear
-
24kV Indoor Epoxy Resin Insulator Bushing
-
Cast Epoxy Resin 40.5kV (35kV) Shielding Wall Through Busbar Bushing (TGZ2-35-B/TGZ2-B-40.5)
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Shuguang Electric | |
| Model Number | TGZ18-10 | Type | Insulation Sleeving | |
| Material | Other, Epoxy Resin | Application | High Voltage | |
| Rated Voltage | 12kV | Tensile Strength | 6000N |
Product Description
Specifications
1.Wall Bushing with 630A Rated Current, Suitable for 12kV Switchgear2.Certificate Standard ISO9001 and Type Test Report
Name:12kV Wall Bushing
Power-frequency Withstand Voltage: 65kV/1min
Partial discharge: ≤10pC
Lightning impulse withstand voltage: 125kV
Glass transition temperature: ≥105°C
Creepage distance:≥240mm
