Delta temperature controller DTB4896 PID Controller DTB4896RR

Specifications

Delta temperature controller DTB4896 PID Controller DTB4896RR
additionally equipped with linear voltage signal output and dual output control,
capable of executing heating and cooling controls simultaneously
in a temperature control system and fast reaching the target temperature.
 PID control / On-Off control / manual input control / programmable control modes
 2 groups of outputs to auto-tuning 2 groups of PID parameters
 Able to connect to various thermocouples (B, E, J, K, L, N, R, S, T, U, TXK), platinum RTD (PT100, JPT100),
analog current (0 ~  20mA, 4 ~ 20mA) and linear voltage (0 ~ 5V, 0 ~ 10V)
 Maximum 3 groups of alarm switches are available, with 18 alarm modes each
 Celsius or Fahrenheit temperature display
 2 key lock functions (1. lock all keys; 2. lock only function keys, up/down keys are still workable)
 Panel sizes: 4824, 4848, 4896, 9696
 Built-in RS-485 communication interface (Modbus ASCII, RTU, baud rate: 2,400 ~ 38,400)
 Sampling time of thermocouple/platinum RTD: 0.4 second/time; sampling time of analog input: 0.15 second/time
 Programmable logic controller is able to set up 64 sets of temperature and control time.
 Optional CT (wire breaking detection) function, an alarm output
 Optional Event function, using PLC or switches to switch between 2 different set temperatures.
 Optional Valve function, adjusting the open/close of the valve by the output value.
Applications
Blower coil pipe in central air-conditioning system, heating system.
Delta temperature controller models: DTB Series models:
DTB9696; DTB4896; DTB4848; DTB4824;
DTB9696RR; DTB4896RR; DTB4848RR; DTB4824RR;
