Q235/Q345 High Quality Steel Welded H Beam by Evelyn

FOB Price

US$ 400 - 500 / Metric Ton

50 Metric Tons(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Grade	SS400
Technique	Other, Hot Rolled, Hot rolled	Thickness	5,7,9,10mm...
Application	construction, H BEAM FOR building	Length	12m
Standard	JIS	Flange Width	200mm,300mm,350mm...
Flange Thickness	5,7,9,10mm...	Web Width	200 300 350mm....
Web Thickness	5,7,9,10mm,........	Brand Name	RUIGUO
Model Number	Q345

Usage:

1.used for the plant, high-rise building construction

2.used for the bridge, shipment building

3.used for lifting and transportation machinery, equipment manufacturing base building

4.used for the support, foundation pile manufacturing

5. Payment terms: 30% tt in advance, the balance against the LC or the copy of BL.

size of h beam

ACCORDING TO STANDARD: JIS G3192 OR GB/T11263-2005
H beam Section sizenma(mm)			Theoretical Weight (kg/m)
Height×Breadth	Web thichness	Flange thichness	JIS Standard	GB Standard
100×50	5	7	9.3	9.54
100×100	6	8	16.9	17.2
125×125	6.5	9	23.6	23.8
148×100	6	9	20.7	21.4
150×75	5	7	14.0	14
150×150	7	10	31.1	31.9
175×90	5	8	18.0	18.2
175×175	7.5	11	40.4	40.3
194×150	6	9	29.9	31.2
198×99	4.5	7	17.8	18.5
200×100	5.5	8	20.9	21.7
200×200	8	12	49.9	50.5
200×204	12	12	56.2	56.7
244×175	7	11	43.6	44.1
248×124	5	8	25.1	25.8
250×125	6	9	29.0	29.7
250×250	9	14	71.8	72.4
250×255	14	14	81.6	82.2
294×200	8	12	55.8	57.3
294×302	12	12	83.4	85
298×149	5.5	8	32.0	32.6
298×201	9	14	64.4	65.9
300×150	6.5	9	36.7	37.3
300×300	10	15	93.0	94.5
300×305	15	15	105.0	106.0
340×250	9	14	78.1	79.7
344×348	10	16	113	115
346×174	6	9	41.2	41.8
350×175	7	11	49.4	50
350×350	12	19	134.9	137.0
388×402	15	15	140	141
390×300	10	16	105	107
394×398	11	18	147	147
396×199	7	11	56.1	56.7
400×200	8	13	65.4	66
400×150	8	13	55.2	55.8
400×400	13	21	172.0	172.0
414×405	18	28	232	233
414×202	10	20	93.9	94.5
428×407	20	35	283	284
440×300	11	18	121	124
446×199	8	12	65.1	66.7
450×200	9	14	74.9	76.5
482×300	11	15	111	115
488×300	11	18	125	129
496×199	9	14	77.9	79.5
500×200	10	16	88.2	89.6
506×201	11	19	102	103
582×300	12	17	133	137
588×300	12	20	147.0	151
594×302	14	23	170	175
596×199	10	15	92.5	95.1
600×200	11	17	103	106
600×304	16	26	194	198
606×201	12	20	118	120
692×300	13	20	163	166
700×300	13	24	182	185
792×300	14	22	188	191
800×300	14	26	207	210
900×300	16	28	240	243


factory

Package

Shipping

Ruiyin International Trade Co., Ltd.(BJ): Contact nameVanny Lee
Chat Now; Phone86-315-5109765; Address 17th Floor, A-Zone, Wanda Plaza, Tangshan City, Hebei Province, China, Tangshan, Hebei
