h Beam Iron h Beam Size Beam
- Xingang port Tianjin China
- T/T Credit Card PayPal
You May Like
-
2015 Tanshan Factory Price T Bars Steel Structure Buildings
-
2015 Tanshan Factory Price T Bars Steel Structures China Online Shopping
-
Wholesale Professional Structural Beams Houses T Bars Steel Building
-
2015 Import Building Materail From China Tanshan Factory Price T Bars
-
HEA/HEB/HN/HM Hot Rolled High Strength Carbon Structural Steel H Beams
-
2015 Import Building Materail From China Construction Use Material H Beam Q235b Steel h Beam
Product Details
| Leg Height | 100-630mm | Depth | 68-180mm | |
| Standard | AISI, ASTM, BS, DIN, EN, GB, JIS, ASTM, BS, DIN, GB | Grade | SS400 - SS490 | |
| Place of Origin | Hebei, China | Brand Name | RGTS | |
| Model Number | 10-63C | Application | construction,shipping,building, construction |
Product Description
h beam iron h beam size standard h beam
Specification:
GB STANDARD I BEAM | |||||||||
|
|
|
|
|
|
|
|
|
|
SIZE(MM) | H(MM) | B(MM) | D(MM) | KG/M | SIZE(MM) | H(MM) | B(MM) | D(MM) | KG/M |
10 | 100 | 68 | 4.5 | 11.261 | 36A | 360 | 136 | 10.0 | 60.037 |
12 | 120 | 74 | 5.0 | 13.987 | 36B | 360 | 138 | 12.0 | 65.689 |
14 | 140 | 80 | 5.5 | 16.890 | 36C | 360 | 140 | 14.0 | 71.341 |
16 | 160 | 88 | 6.0 | 20.513 | 40A | 400 | 142 | 10.0 | 67.598 |
18 | 180 | 94 | 6.5 | 24.143 | 40B | 400 | 144 | 12.5 | 73.878 |
20A | 200 | 100 | 7.0 | 27.929 | 40C | 400 | 146 | 14.5 | 80.158 |
20B | 200 | 102 | 9.0 | 31.069 | 45A | 450 | 150 | 11.5 | 80.420 |
22A | 220 | 110 | 7.5 | 33.070 | 45B | 450 | 152 | 13.5 | 87.485 |
22B | 220 | 112 | 9.5 | 36.524 | 45C | 450 | 154 | 15.5 | 94.550 |
25A | 250 | 116 | 8.0 | 38.105 | 50A | 500 | 158 | 12.0 | 93.654 |
25B | 250 | 118 | 10.0 | 42.030 | 50B | 500 | 160 | 14.0 | 101.504 |
28A | 280 | 122 | 8.5 | 43.492 | 50C | 500 | 162 | 16.0 | 109.354 |
28B | 280 | 124 | 10.5 | 47.888 | 56A | 560 | 166 | 12.5 | 106.316 |
30A | 300 | 126 | 9.0 | 48.084 | 56B | 560 | 168 | 14.5 | 115.108 |
30B | 300 | 128 | 11.0 | 52.794 | 56C | 560 | 170 | 16.5 | 123.900 |
30C | 300 | 130 | 13.0 | 57.504 | 63A | 630 | 176 | 13.0 | 121.407 |
32A | 320 | 130 | 9.5 | 52.717 | 63B | 630 | 178 | 15.0 | 131.298 |
32B | 320 | 132 | 11.5 | 57.741 | 63C | 630 | 180 | 17.0 | 141.189 |
32C | 320 | 134 | 13.5 | 62.765 |
|
|
|
|
|
