60kw Low Noise Diesel Generator With ATS ,engine LR4B3Z-D
- Qingdao
- T/T
You May Like
-
Supermaly Emergency Generator 500kva Standby Generator With ATS
-
Supermaly Emergency Generator Diesel Power Station 60kva
-
Supermaly Canopy Diesel Generator 160kva
-
Supermaly Electric Power Generation 60 kw
-
Generating Equipment Home Standby Generator
-
OEM Manufacturer High Quality Silent Diesel Generator 20kva
Product Details
| Place of Origin | Shandong, China | Brand Name | Supermaly | |
| Model Number | SL60GF | Output Type | AC Three Phase | |
| Speed | 1500rpm | Frequency | 50HZ | |
| Rated Power | 60KW | Rated Voltage | 400V | |
| Rated Current | 108A |
Product Description
Parameter of 60kw low noise diesel generator with ATS ,engine LR4B3Z-D :
| Cummins Series Diesel Generator | ||||||
| Genset Model | Open Type | SL60GF | ||||
| Silent Type | SL60GFS | |||||
| Unit Price FOB QINGDAO | Open Type | |||||
| With Stamford Alternator | Silent Type | |||||
| Prime Power(kW/kVA) | 60/75 | |||||
| Standby Power(kW/kVA) | 66/82.5 | |||||
| Diesel Engine | Model | LR4B3Z-D | ||||
| Type | water-cooled, inline, 4-stroke, direct injection ,wet cylinder liner,1500rpm | |||||
| Rated Power(kW) | 66 | |||||
| Intake Type | Turbocharged | |||||
| No.of Cylinder | 4.L | |||||
| Bore x Stroke(mm) | 103x127 | |||||
| Compression Ratio | 16:1 | |||||
| Mechanical Governor Rate | withiin 5% | |||||
| Electronic Governor Rate | within1% | |||||
| Noise Level (dBA) | within 95 | |||||
| Exhaust Temperature(°C) | 561 | |||||
| Lub oil Capacity(L) | 8.1 | |||||
| Rated Fuel Consumption(L/h) | 16.2 | |||||
| Alternator | Model | 224F | ||||
| Rated Power(kW/kVA) | 60/75 | |||||
| Power Efficiency | 88.9% | |||||
| Voltage Regulation | within±1 | |||||
| Excitation Type | Brushless | |||||
| Insulation Class | H | |||||
| Overall Size(mm) | Length | 2250 | ||||
| Width | 845 | |||||
| Height | 1650 | |||||
| Gross Weight(kg) | 1050 | |||||
Feature of 60kw low noise diesel generator with ATS ,engine LR4B3Z-D :
1.Supermaly diesel generator set ,our facotry is the OEM of Cummins engine,wudong engine,yuchai engine and ect,so we can give you more cheapper price.
2.Stamford alternator ,Marathon alternator is the optional.
3.with control panel and 8-10 hours base fuel tank.
4.ATS and AMF is the optional.
5.1year or 1500 hours warranty.
6.10-25days delivery.If in store,2 days.
Besides ,You can also choose :
Engine :
Perkins (Uk)
Cummins (Usa/China)
Deutz engine(Germany)
MTU (Germany)
Doosan(Korea)
Weichai engine(China)
Shangchai engine(China )
Yuchai engine (China)
Alternator :
Stamford
Marathon
Chinese
Control System :
Deepsea
CoMaP
Smargen
We have established business relationship with 28 provinces,municipalities and autonomous regions,mainly export products to over 40 countries and regions in Europe,Africa,South America,Southeast Asia,West Asia and Others .
60kw low noise diesel generator with ATS ,engine LR4B3Z-D Certificate:
We are the OEM factory ,Perkins,Cummins ,Yuchai ,Weichi and so on ,all of them are our partner .
| Q: Could I use my own LOGO or design on goods? |
| A: Yes, customized logo and design are available. |
| Q: Can I choose the color of diesel generator? |
| A: Yes, customized color is available. |
| Q: What is the delivery time? |
| A: 10-25days. |
| Q: How to installation diesel generator? |
| A: Overseas engineering service available. |
| Q: what is the payment term? |
| A: TT, LC at site, Western Union etc. |
