Home > Products > New Products > P16 outdoor led billboards
P16 outdoor led billboards
US$ 1,000 - 1,800
/ Set
1 Set(Min. Order)
- Shenzhen Hongkong
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | DFB Electronic | |
| Model Number | OMD-View Series-P16 | Usage | Outdoor | |
| Tube Chip Color | Full Color | Display Function | Video | |
| Pixels | 16mm |
Product Description
Outdoor Full Color LED Display
(Solution for Outdoor Medium Viewing Distance)
OMD-View Series
Viewing distance: 15-300m
Recommend Minimum Screen size: 12-24 M2
Features:
- Pixel pitch 16mm, led density 3906pixels/square meter
- Applicable in rental business and fixed installation business.
- High standard in base material selection, to reach up best cost/performance ratio
- Good quality, high brightness oval outdoor leds, brightness up to 8000nits.
- Professional Color calibration system to make sure the color and brightness uniformity, no “mosaic” “glare” “splash” symptom in white balance.
Applications:
1. Outdoor rental (super slim, light weight rental panel)
2. Outdoor fixed installation
3. Outdoor perimeter screen
4. Outdoor truck/trailer display
5. Others….
Specifications:
| Spec | ||
| Pitch | PH16 | PH16 |
| LED Lamp Model Type | Oval led | Oval led |
| Pixel Config | 1R1G1B | 2R1G1B |
| Brightness (6500Kelvin) | 7000 Nits | 7000 Nits |
| Panel Size | 1024×768 | 1024×768 |
| Panel Resolution | 64×48 | 64×48 |
| IP Rating | IP65/IP54 | IP65/IP54 |
| Panel Net Weight(Steel) | 50 kgs | 50 kgs |
| Pixel Density (/sqm) | 3906 | 3906 |
| Horizontal Viewing Angle (dgr.) | 110 | 110 |
| Vertical Viewing Angle (dgr.) | 60 | 60 |
| Best Viewing Distance | 16m | 16m |
| Recommend Min Screen Size | 12 m2 | 12m2 |
| Input Voltage | AC110V/220, 60/50Hz | |
| Power Consumption -Max (/Sqm) | 1.1 kw | 1.4 kw |
| Power Consumption -Ave. (/Sqm) | 0.4 kw | 0.5 kw |
| Driving Mode | Constant Static Current | Constant Static Current |
| Communication Profile | RS232/WIFI/Network/USB | |
| Gray Scale | 16384 | |
| Brightness Level | 16 Ranks | |
| Refesh Frequency | 400-1200Hz Adjustable | |
| Pixels Lost Control | <300ppm | |
| Colors | 4.4 Trillion Colors | |
| Operate Temperature | -20°C~70°C | |
| Operate Humidity | 10%~95%RH | |
Installations:
Module Viewing:
Project Viewing:
