ThinPAD P6 ultrathin and light weight indoor rental led display

FOB Price

USD $3,000 - $4,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Thin Pad Series-Indoor rental led display

Viewing distance: 2-200m

Recommend Minimum Screen size: 1-3 M²

Features:

Available pixel pitch 6mm, 6.25mm
High-quality LED, high efficiency luminescence up to 2000nits.
Color cast solved with the state of the art SMD tech, super black body SMD Leds, 2000:1 color contrast ratio.
Digital aluminum modeling base solution for heat ventilation, none-fan silent cooling system, advanced processing technology to guaranty long lifetime.
Ultra thin panel design, width less than 40mm, weight only 8KG/panel
Professional color calibration system to make sure the color and brightness uniformity, no “mosaic” “glare” “splash” symptom.
Fast hold and assembly design to satisfy the rigorous rental application
High pixel density to assure the perfect viewing quality even within a short viewing distance less than 3 meter.
Advanced control system, 16bit color processing technology, 1200-2000Hz refresh rates to avoid scan line even under the high definition living camera.
Energy saving designing, power consumption to be decreased by 35-50%.

Specifications
Pitch	PH6mm	PH6.25mm
LED Lamp Model Type	SMD 3in1	SMD 3in1
Brightness (6500Kelvin)	1000 Nits	1000 Nits
Panel Size	480×480	500×500
Panel Resolution	80×80	80×80
IP Rating	IP31/IP33	IP31/IP33
Panel Net Weight(Steel)	8 kgs	8 kgs
Pixel Density (/sqm)	27777	25600
Horizontal Viewing Angle (dgr.)	140	140
Vertical Viewing Angle (dgr.)	120	120
Best Viewing Distance	6m	6.5m
Recommend Min Screen Size	3-4 sqm	2-4sqm
Input Voltage	110/220 V
Power Consumption -Max (/Sqm)	0.8 kw	0.75 kw
Power Consumption -Ave. (/Sqm)	0.3 kw	0.25 kw
Driving Mode	1/8 Scan rate	1/8 Scan rate
Communication Profile	RS232/WIFI/Network
Gray Scale	16384
Brightness Level	16 Ranks
Refesh Frequency	200-1200Hz Adjustable
Pixels Lost Control	<300ppm
Colors	4.4 Trillion Colors
Operate Temperature	-20°C~70°C
Operate Humidity	10%~95%RH

Panel Details Overview
