Product Details

Outdoor Full Color LED Display

(Solution for Outdoor Short Distance Viewing)

OSD-View Series

Viewing distance: 8-200m

Recommend Minimum Screen size: 4-12 M²

Features:

Pixel pitch 10mm, led density 10000pixels/square meter
IP65 Rating to insure the good working even if under the fierce environment with strong wind, sandstorm, rainstorm…etc.
High standard in base material selection, to reach up best cost/performance ratio
Good quality, high brightness oval outdoor leds, brightness up to 8000nits.
Professional Color calibration system to make sure the color and brightness uniformity, no “mosaic” “glare” “splash” symptom in white balance.

Specifications:

	Spec
Pitch	PH10mm
LED Lamp Model Type	Oval led
Pixel Config	1R1G1B
Brightness (6500Kelvin)	8000 Nits
Panel Size	960×800
Panel Resolution	96×80
IP Rating	IP65/IP54
Panel Net Weight(Steel)	40 kgs
Pixel Density (/sqm)	10000
Horizontal Viewing Angle (dgr.)	110
Vertical Viewing Angle (dgr.)	60
Best Viewing Distance	10m
Recommend Min Screen Size	4 m²
Input Voltage	AC110V/220, 60/50Hz
Power Consumption -Max (/Sqm)	0.8 kw
Power Consumption -Ave. (/Sqm)	0.4 kw
Driving Mode	1/4 Scan rate
Communication Profile	RS232/WIFI/Network
Gray Scale	16384
Brightness Level	16 Ranks
Refesh Frequency	400-1200Hz Adjustable
Pixels Lost Control	<300ppm
Colors	4.4 Trillion Colors
Operate Temperature	-20°C~70°C
Operate Humidity	10%~95%RH

Installations

Module Viewing

Project Viewing
