diesel generating sets powered by Korea diesel engine

W.D Power Generator Pictures in details

50Hz-Three Phase-Power Factor 0.8

Rating

Prime Power

Standby Power

Rated Current

Voltage (V)

KVA/KW

KVA/KW

(Amp)

220V/380V

370/296

407/325

562.1

230V/400V

344/275

375/300

534.3

240V/415V

344/275

375/300

514.7

Engine Specification General Performance

Engine Model:

DOOSAN DAEWOO P158LE-1

Engine Type:

4 cycle, V-type, 8-cylinder

Engine Speed:

1500 r.p.m

Base Output Power:

327kW/438Hp

Standby Power:

362kW/485.3Hp

Governor Type:

Electronic

Air Intake Way:

Turbocharged & Intercooled (air to air)

Displacement:

14.618L

Cylinder Bore * Stroke:

128mm × 142mm

Compression Ratio:

15:1

Coolant Capacity Engine Only

20 Litres

Alternator Specification General Performance

Engine Model:

Stamford     HCI444FS

Phase

3 Phase

Power Factor

0.8

Drip Proof

IP 23

Insulation class

H

Voltage regulation

± 0,5 %

Altitude

≤ 1000 m

Over speed

2250 min -1

Scope of supply

Standard

Optional

High efficient water cooled diesel engine

Automatic Transfer Switch (A.T.S)

Brushless alternators (Class H, with AVR.)

Water - Fuel separator

Heavy duty rubber anti-vibration mountings

Water heater for severe cold weather

24V starter batteries and connecting cables

Lub-oil heater for severe cold weather

Industrial silencer

Low coolant level sensor

Auto start Digital Control Panel

Dual wall base fuel tank

Radiator with cap and drain point

Fuel level sensor

Fully guarded engine driven fan

ABB  brands Breakers

Circuit Breaker

Separated standing fuel tank

Soundproof canopy for silent genset

Alternator Space Heater

Oil filter - Diesel filter - Air filter

DSE6020,DSE7320,ComAp AMF25 controller

50℃ Radiator

Customized 24H,48H base fuel tank

Benefits of Silent Type Generator Sets

1. Stable function, convenient service;
2. Low operating cost results in optional economy;
3. Gets the job done wherever you are;
4. Ease of installation, operation and maintenance.

For silent type, the noise level can be 70-76db(A) at 7M; with silent canopy, the genset can

be soundproof, rainproof, rustproof, dustproof and more safe.

W.D Power Factory& Production Flow

W.D Power Testing System

Before deliver gensets to you each generator set we will test the quality for 1.5 hour with

below performance:

--Different loading performance (0%,25%,50%,75%,100%)

--Heat run test

--Insulation resistance test

--starting test

--tests of all alarm and timing relays

W.D Power Package&Delivery

Plastic Poly-ether (Export Standard),Wooden case,Plywood case.

W.D Power Warranty

12months or 1000hr (subject to the earlier mature term)

W.D Power Service

1. Production capability 300Set/month and Quickly delivery time

2. Competitive price: Perkins,DCEC/CCEC,Deutz,Stamford,Leroysomer OEM available

3. Full one hour factory quality testing with various loading at 25%,50%,75%,100%,110%

4. 1000hours or 12months warranty

5. Spare parts support and W.D Power technical support also technical training served.

6. R&D team support and sales team 24hours on-line service

Manual and catalog

Full set of Engine/Atlernator/Generator operation&maintenance manuals are provide

with each generator.

Introduction to  Doosan

DOOSAN Group founded in 1896 is one of the largest consortium in Korean currently. Doosan Engine is established after the acquisition of Daewoo Integrated Machinery Co., Ltd in 2005, named Doosan Engineering Machinery, and continue todevelop and launch a new generation product with first class and reliable performance base on the original Daewoo engine.
