GHB Modular 1080i /1080P HD-SDI Fiber Link/optical transmitter/optical terminal

GHB Modular HD-SDI Fiber Link

GHB modular fiber link includes GHBT optical transmitter module and GHBR optical receiver module for 1080i HD-SDI signal or 1080P HD-SDI signal.  The HD-SDI channel number over GHB fiber link can be up to 4 over one SM fiber. The GHBT transmitter can be installed next to HD camera while GHBR optical receiver can be installed next to the HD-SDI processing equipment via coaxial digital cable. HD-SDI signal can be 1920x1080 30P or 60P. GHB supports the reverse RS-485 PTZ control signal transmission to each connected HD camera over the same SM fiber. GHBT optical transmitter can work with GHBR receiver or GHCR receiver (multi HD-SDI optical receivers in 19” 1RU chassis)

Features:

l         Auto Negotiate 19.4/143/177/270/360/540/1483.5/1485Mbps and 2970Mbps

l         Complied with SMPTE424M, SMPTE292M, SMPTE310M, SMPTE259M and SMPTE344M

l         Complied with DVB-ASI (EN50083-9)

l         Cable Input Equalizer on the transmitter and clock recovery on the receiver

l         Built-in Diplexer module for single fiber reverse data transmission

l         Pathological Pattern Available upon request

Specifications:

Test Data of GHB over 20Km SM fiber

Left: 1080P 30P HD-SDI signal over 20Km SM fiber Eye Diagram

Left: 1080P 60P HD-SDI signal over 20Km SM fiber Eye Diagram

Left: 1080P 60P HD-SDI signal at Pathological Pattern

Left: 1080P 60P HD-SDI signal at Pathological Pattern over 20Km fiber Eye Diagram

Ordering Information: GHBT-W-X-Y-Z-S  Modular HD-SDI Optical Transmitter

                                    GHBR-W-Y-Z-S  Modular HD-SDI Optical Receiver

W(HD-SDI Channel): 1 or 2 or 4

X(Fiber Distance): 2-2Km, 10-10Km, 20-20Km, 40-40Km,…

Y(Reverse Data): None-No Data, D-RS485

Z(Fiber Connector): FU-FC/UPC, SU-SC/UPC, FA-FC/APC, SA-SC/APC

S(Special Requirement): None-1080i 1.485Gbps; P-1080P 2.97Gbps,

PB-1080P HD-SDI supporting pathological pattern
