Home > Products > Photoelectric sensor > M18 Connector Type Through Bream Infared Photo Electric Sensor Switch With M12 Connector

M18 Connector Type Through Bream Infared Photo Electric Sensor Switch With M12 Connector

FOB Price

US$ 10 - 12 / Piece

5 Pieces(Min. Order)

Port ZhongShan Port

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	IBEST
Model Number	PESI-T18PO10MD; PESI-T18POC10MD	Usage	Other, photo sensor
Theory	Other, Infared photo sensor	Output	Other, PNP, NPN, NO, NC, NO+NC, AC 2 Wire

Product Description

Specifications

M18 Photo Switch
1.DC 3 wire or 4 wire;
2.PNP or NPN(NO/NC/NO+NC) or Ac 2 Wire
3.CE
4.With Red LED Indicator

1.Features of IBEST M18 Photo Switch :

-- Style: cylinder, diameter: 18mm.

-- Through-beam type, retro-reflective type and diffused-reflective type.

-- DC 3 wire or 4 wire; with or without M12 plug-in connector connection.

-- PNP or NPN; NO or NC or NO+NC

-- Light resource: Infrared LED -- Strong anti-shock and anti-vibration.

-- Long detect distance: through-beam: 10m / retro-reflective type: 3M / diffused-reflective: 5~50cm

-- Fast response: through-beam: <5ms / diffusec-reflective: <3ms -- Non-contact object detect: avoid the photoelectric sensor to contact the object directly, protect the inducing component from damage and extend the operation life of the sensor. -- Detect any objects with different materials: detect objects by the light quantities reflected and received, detect objects such as glass, metal, plastic, wood, fluid...etc. -- Identify object colors: according to the colors' reflectivity and absorptivity, the sensors detect the light that the object reflected and identify the colors. -- High precision: precise electron circuit, can detect tiny objects with accurate position.

-- IP ratings: IP67 -

- Various other shapes: M12/M30 and square types.

2. Ordering Code:

PESI-T18PO10MD	Through Beam	PNP NO	10M	≤200mA	DC 10-30V
PESI-T18POC10MD	Through Beam	PNP NO + NC	10M	≤200mA	DC 10-30V
PESI-T18NO10MD	Through Beam	NPN NO	10M	≤200mA	DC 10-30V
PESI-T18NOC10MD	Through Beam	NPN NO + NC	10M	≤200mA	DC 10-30V

3. Technical Specifications:

Property project	Specific parameter
Detecting distance range	Through-beam:10m / Retro-reflective: 3m/ Diffusec-reflective:10cm or30cm
Rated power supply	DC:10-30V / AC:90-250V
Current	DC 3 Wrie: ≤200mA / DC 2 Wire:≤100mA / AC 2 Wire:≤400mA
Resonse time	Through-beam:<5ms / Retro-reflective & Diffused-reflective:<3ms
Working angle	Through-beam:3°-20°/Retro-reflective:1°-5°
Voltage for transistor	<1.5V
Current consumption	<20mA
Different distance	<15%
Polarity reverse protection	Yes
Ambient light(LUX)	Incandescent lamp:≤3000 / Sunlight:≤10000
IP ratings	IP 67
Material	Brass nickle plated or ABS

Our company is a professiona manufacutures of:

1, Sensors: inductive proximity sensor, capacitive proximity sensor, photo sensor, hall sensor, color mark sensor and analog sensor.

2, Digital meter: temperature controller, digital counter, digital timer, digital frequency/tacho/linespeed meter, digital panel meter, analog panel meter ...etc.)

3, Solid state relay: single phase and 3 phase

4, Rotary encoder and couplings

5, Various type of cable and connectors..etc.

6, Pressure transmitters.

7, Safety light curtain.

Welcome to contact us!
