Hydraulic Oil Pressure Gauge

hydraulic oil pressure gauge
Standard packing(or according to the customer request)

Hydraulic oil pressure gauge

Technical performance
Range: 0.1 ~ 0 ~ 100 mpa
Accuracy : 0.2 % 0.5%

Overload capacity : 200%
Type : gauge

The stability : ≤0.1% /year

The battery voltage: 9 VDC
Display :LCD
Display range:-1999-9999
Ambient temperature: - 20 °C ~ 70 °C
Relative humidity : ≤80%
Install thread :M20 * 1.5
Interface material :stainless steel

Features:

Large-screen LCD display, high resolution
Peak hold function to record the maximum pressure during the measurement value
Pressure percentage dynamic display, (the progress bar shows)
Five kinds of engineering unit selection: psi, bar, kpa, kg / cMpa
Select 1 ~ 15min automatic shutdown feature.
Micro-power, power-saving mode can work in more than two years of continuous work 2000 hours.
Parameter correction function, the instrument can live zero error value correction.
Upper and lower limit range
Sampling rate: 4 times / sec.
Apply pressure of various gases compatible with stainless steel measuring liquids

About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.

If you need this Digital Pressure Gauge , please contact skype:wangxiaoyuncalar
