P10 Single Color Module Red Blue Green Yellow White

FOB Price

US$ 4 - 4.6 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	DY-mp10
Model Number	Outdoor P10 single color module, P10 single color module red blue green yellow white	Usage	Other, Outdoor, Outdoor
Tube Chip Color	Other, Red, Red	Display Function	Video
Pixels	10mm	Screen Dimension	320mm*160mm

P10 single color module red blue green yellow white

The technical parameter of P10 Display Module
Number	Item	P10 Single Red Module
1	Pixel pitch	10mm
2	Size of module(wxh)	320mm X160 mm
3	Resolution of module (wxh)	32 dots X16 dots
4	Density of pixel	10000dots/m²
5	Pixel configuration	1R or 1G or 1B or 1W
6	Red wavelength	625±2nm
7	Green wavelength	525±2nm
8	Blue wavelength	470±2nm
9	Colors	Red
10	Best viewing distance	10-100m
11	Horizontal viewing angle	120°
12	power consumption	200w/m²
13	Brightness	>2500cd /m2
14	Gray scale	16bits per color
15	Color temperature	5500k
16	Control method	Synchronization & Asynchronization
17	Driving method	1/4 scanning
18	Frame frequency	60Hz
19	Refresh frequency	>300Hz
20	Working voltage	AC220V/110V±10%
21	IP grade	IP65
22	Working temperature	-20°C~80°C
23	MTBF	>10000 hours
24	Lifespan	>100,000 hours
25	Defects rate	≤0.00001(Led display line standard<0.0001)
