Product Details
| Place of Origin | Shanghai, China | Brand Name | SUMLUNG | |
| Model Number | SL-UHF9241M |
Product Description
UHF RFID Reader and Writer Module
RS232 interface
Features
Small, easy to be embedded into RFID facilities, convenient to use
Functions: Read, write, authorization, formatting UHF cards, tags, labels
With acousto-optic status indication
Specifications | |
Operating Frequency | 860 ~ 960 MHz (Adjustable for local regulation) |
Protocol | ISO18000-6B, EPC Class 1 GEN 2, ISO10374(Container standard), , TB/T3070-2002(Railway standard) |
Operating Mode | FHSS or fixed frequency (set by software) |
Antenna | Built-in |
Power Smoothness | < 0.5 DB |
RF Power Range | 20 ~ 30 dBm (set by software) |
Indicator | Buzzer, LED indicator |
Working Mode | Identify tag mode can be set as: 1) Auto-reading tag in fixed time (Timing Mode) 2) Reading tag by external trigger (Trigger Mode) 3) Software command(Master-slave mode) |
Read/Write Time | Read < 5ms per 8 bytes; Write < 25ms per 4 bytes |
Read/Write Distance | Reading distance > 40 cm Writing distance > 28 cm (depends on tag and environment) |
Communication Interface | RS232/TTL, Wiegand 26/34/42/50, RS485/TTL(optional) |
Power Supply | AC input: 100~240V, 50/60Hz 1.2A DC output: 5V/5A |
Power consumption | ≤ 5 W |
Working Temperature | -20°C ~ 70°C (-4°F ~ 158°F) |
Storage Temperature | -40°C ~ 85°C (-40°F ~ 185°F) |
Module Size | 89 * 62 * 4.8 mm |
Packing Size | 89 * 62 * 15 mm(including built-in antenna) |
Net Weight | 41 g |
Accessories | RS-232 cable |
Applications
Traffic management: ETC, customs border-crossing, parking lot, automatic weighing etc.
Logistics: Container management, pallet management, asset tracking, etc..
Ticketing
Time Attendance
Access Control
RFID embedded system development
Package includes
1* UHF RFID Reader Module SL-UHF9241M, RS232 interface
1 * RS232 cable
